DiodesZetex 30 V 200 mA Surface Mount Schottky Barrier Diode Switching 2-Pin SOD-123 BAT43W-7-F

DiodesZetex BAT43W-7-F is a surface mount Schottky barrier diode specifically designed for efficient switching applications requiring low forward voltage drop and fast switching capabilities. With a maximum forward current of 200 mA and peak reverse voltage of 30 V, this two-pin SOD-123 packaged diode offers excellent performance in compact electronic circuits.

The diode features a very low forward voltage drop of 450 mV which reduces power dissipation and enhances energy efficiency. Its fast peak reverse recovery time of 5 ns supports high-speed switching in power supply, rectification, and voltage clamping circuits.

The compact physical size, measuring just 2.85 mm in length, 1.7 mm in width, and 1.35 mm in height, allows for space-saving board designs. It operates reliably over a wide temperature range from -55°C to 125°C, suitable for industrial, automotive, and consumer electronics applications.

This diode is rated to handle peak non-repetitive forward surge currents up to 4 A, providing robustness against transient voltage spikes and surges. The single diode configuration and surface mount form factor are optimized for efficient PCB assembly, enhancing production efficiency.

Applications span power management circuits, switching supplies, rectifiers, and general semiconductor switching needs in industrial and commercial electronic systems. Maximum continuous forward current of 200 mA. Low forward voltage drop of 450 mV.

Peak reverse repetitive voltage of 30 V. Fast peak reverse recovery time of 5 ns. Compact SOD-123 surface mount package. Wide operating temperature range from -55°C to 125°C. High peak non-repetitive forward surge current of 4 A.

Single diode configuration for versatile use. Manufactured in China with quality assurance. Explore the extensive category of Schottky Diodes and Rectifiers at EnvMart for more semiconductor options tailored to your electronic design requirements.
