DiodesZetex Surface Mount Schottky Diode 30 V 3 A 2-Pin DO-214AB Package B330-13-F

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex Surface Mount Schottky Diode 30 V 3 A 2-Pin DO-214AB Package B330-13-F

Name: DiodesZetex Surface Mount Schottky Diode 30 V 3 A 2-Pin DO-214AB Package B330-13-F
Brand: DiodesZetex
SKU: 363524
Price: 0.2 USD
Availability: InStock



Category Schottky Diode Brand DiodesZetex Condition New

Specifications

Country of Origin	India
Brand	DiodesZetex
Height	2.3mm
Length	7.11mm
Model	B330-13-F
Width	6.22mm
Mount Type	Surface
Series	B330
Maximum Operating Temperature	125°C
Package Type	DO-214AB (SMC)
Minimum Operating Temperature	-55°C
Standards/Approvals	FBI
Pin Count	2
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	3A
Peak Reverse Repetitive Voltage Vrrm	30V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	20mA
Peak Non-Repetitive Forward Surge Current Ifsm	100A
Maximum Forward Voltage Vf	500mV

Key Features

This diode is designed for use in power rectification with low forward voltage drop.
The Schottky configuration ensures fast switching and high efficiency.
It features robust automotive standard AEC-Q101 qualification for reliability.
Operating temperature range from -55°C to 125°C suits harsh industrial environments.
Compact dimensions of 7.11 mm length, 6.22 mm width, and 2.3 mm height facilitate PCB design flexibility.
Peak non-repetitive forward surge current capability is 100 A for transient overloads.
Forward voltage max of 500 mV reduces power loss in circuits.
Single diode configuration with two pins supports surface mounting.

Product Description

DiodesZetex B330-13-F is a high-performance surface mount Schottky diode designed for industrial and automotive applications requiring efficient power rectification. This device supports a maximum continuous forward current of 3 A and a peak reverse repetitive voltage of 30 V, making it ideal for switching power supplies, inverters, and freewheeling diodes in DC/DC converters.

The diode package is DO-214AB (SMC), a small outline package allowing compact board footprints while maintaining excellent thermal characteristics. It features a low forward voltage drop of up to 500 mV which minimizes conduction losses and improves overall system efficiency.

With a peak non-repetitive forward surge current rating of 100 A, the diode can handle transient power surges common in automotive and industrial environments. The device is qualified per automotive standard AEC-Q101, ensuring reliability under rigorous conditions.

The operating temperature range from -55°C to 125°C supports a wide range of industrial applications including power management, voltage clamping, and reverse polarity protection in harsh environments. Its 2-pin single diode configuration simplifies circuit design and assembly with surface mounting technology.

Dimensional attributes are 7.11 mm in length, 6.22 mm width, and 2.3 mm height, enabling easy integration on printed circuit boards with space constraints. The diode's robust construction and stable performance characteristics make it suitable for use in consumer electronics, telecommunications, automotive electronics, and industrial manufacturing processes.

This Schottky Diode provides low forward voltage drop for efficient switching. Automotive grade AEC-Q101 ensures high reliability in challenging conditions. Operable across a wide temperature range from -55°C to 125°C. High surge current rating supports transient load applications.

Compact DO-214AB package enhances PCB design versatility.

Consider DiodesZetex B330-13-F for your semiconductor component needs targeting power rectification, automotive electronics, and industrial control systems. Explore more semiconductors and related components on EnvMart for your advanced electrical design requirements.
