DiodesZetex 1 A 40 V Surface Mount Schottky Diode DO-214AA B140HB-13-F

DiodesZetex B140HB-13-F is a high-quality Schottky barrier diode designed for surface mounting in electronic circuits. It supports a maximum continuous forward current of 1 ampere and a peak reverse voltage of 40 volts, making it suitable for efficient power rectification and low voltage drop applications. Packaged in a compact DO-214AA form factor, this diode ensures reliable performance in compact and automated assemblies.

The device features a low maximum forward voltage of 700 millivolts which contributes to lower power losses and improved thermal management. It operates effectively across a wide temperature range from -55°C to 150°C, providing robustness for industrial, power supply, and semiconductor applications.

Technical characteristics include a peak non-repetitive forward surge current capacity of 430 amperes, a compact physical profile with dimensions of 4.57mm length, 3.94mm width, and 2.3mm height, and compliance with FBI quality standards. Although not certified for automotive use, it remains ideal for laboratory equipment, manufacturing electronics, and general semiconductor integration.

The diode is surface mount compatible, enabling efficient PCB assembly. Its Schottky configuration results in fast switching and low forward voltage drop. Suitable for both industrial and commercial semiconductor applications.

Compact packaging supports flexible and space-saving designs. Well-suited for use in power supplies, rectifiers, and general purpose electronics. Set includes the DiodesZetex B140HB-13-F diode in a 2-pin DO-214AA package, perfectly tailored for automated manufacturing processes and efficient insertion into machinery.
