Vishay Fast Recovery Diode 400 V 30 A 3-Pin TO-247AC VS-60CPU04-N3
Specifications
| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Height | 20.7mm |
| Length | 15.87mm |
| Model | VS-60CPU04-N3 |
| Width | 5.31mm |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-247AC |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 30A |
| Peak Reverse Repetitive Voltage Vrrm | 400V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Fast Recovery |
| Peak Reverse Current Ir | 100μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 300A |
| Maximum Forward Voltage Vf | 1.3V |
| Peak Reverse Recovery Time trr | 65ns |
Key Features
- It features a common cathode diode configuration for efficient switching.
- Housed in a TO-247AC package with three pins for through-hole mounting.
- Maximum forward voltage drop of 1.3 V ensures low power loss.
- Operational temperature range from -65°C to 175°C supports harsh environments.
- Peak non-repetitive forward surge current of 300 A handles transient overloads.
- Low peak reverse current of 100 μA reduces leakage in circuits.
- Fast peak reverse recovery time of 65 ns enhances high-frequency performance.
- Compact size with dimensions 20.7 mm height, 5.31 mm width, and 15.87 mm length.
Product Description
Vishay VS-60CPU04-N3 is a high-performance fast recovery diode designed for demanding power electronics applications. It offers a peak reverse voltage of 400 V and a maximum continuous forward current of 30 A, making it suitable for efficient rectification and switching tasks in industrial, electronic components, and power supply systems.
The device is built with a common cathode diode configuration and packaged in the TO-247AC case, featuring a 3-pin through-hole mount that provides robust mechanical stability on printed circuit boards. Its maximum forward voltage drop of 1.3 V ensures minimized power dissipation, which enhances energy efficiency in circuits.
This diode supports a broad operating temperature range from -65°C to 175°C, allowing reliable performance under extreme thermal conditions. With a peak non-repetitive forward surge current rating of 300 A, it can withstand transient overloads typical in power switching applications. Additionally, the low peak reverse current of 100 μA minimizes leakage currents, contributing to overall system reliability.
The rapid peak reverse recovery time of 65 nanoseconds permits efficient switching at high frequencies, making this diode ideal for use in high-speed rectification scenarios. Its compact physical dimensions of 20.7 mm height, 5.31 mm width, and 15.87 mm length aid in space-constrained electronic designs.
Manufactured in China, this Vishay diode is a reliable choice for engineers and designers looking for durable and efficient semiconductor components to enhance power conversion, regulation, and switching in industrial, electronic, laboratory, and commercial equipment.
Common cathode diode configuration. TO-247AC package type with 3 pins. Maximum continuous forward current of 30 A. Peak reverse voltage of 400 V. Forward voltage drop maximum 1.3 V. Operating temperature range from -65°C to 175°C.
Peak surge current 300 A. Fast reverse recovery time of 65 ns. Compact size supporting through-hole mount. Suitable for power electronic and industrial applications. Explore more Vishay semiconductor components and Diodes in EnvMart's Electronics & Electricals category for reliable, high-quality industrial parts.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay VS-60CPU04-N3 diode is 30 A.
This diode has a peak reverse voltage rating of 400 V.
The VS-60CPU04-N3 features a common cathode diode configuration.
The maximum forward voltage drop for this diode is 1.3 V.
This diode operates within a temperature range of -65°C to 175°C.
The dimensions of the VS-60CPU04-N3 are 20.7 mm in height, 5.31 mm in width, and 15.87 mm in length.
The peak non-repetitive forward surge current rating for this diode is 300 A.
The peak reverse recovery time for the VS-60CPU04-N3 is 65 ns.
This model is housed in a TO-247AC package type.
The peak reverse current for the Vishay VS-60CPU04-N3 is 100 μA.
The VS-60CPU04-N3 supports through-hole mounting.
This diode is manufactured in China.
