Panasonic Surge Absorber V Series 400 pF Capacitance 50 A Clamping Voltage 1355 V Model ERZV14D471
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 15.5mm |
| Brand | Panasonic |
| THICKNESS | 6.2mm |
| Length | 38.5mm |
| Model | ERZV14D471 |
| Depth | 6.2mm |
| Mount Type | Radial |
| Series | V |
| Energy Rating | 0.4J |
| Maximum Operating Temperature | 85°C |
| Capacitance | 400pF |
| Minimum Operating Temperature | -40°C |
| Maximum dc Voltage | 670V dc |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 720-9970PBrand: PanasonicManufacturers Part No.: ERZV14D471 |
| Pin Count | 2 |
| Termination Style | Crimped Lead |
| Lead Pitch | 7.5mm |
| Maximum AC Voltage | 505V ac |
| Clamping Voltage VC | 1355V |
| Clamping Current | 50A |
| Maximum Surge Current | 6kA |
| Varistor Voltage | 470 V |
Key Features
- High surge current handling capacity suitable for compact installations.
- Metal oxide varistor with 15.5 mm diameter for reliable performance.
- Radial mount type with crimped lead termination for easy installation.
- Operating temperature range from -40°C to 85°C for versatile usage conditions.
- Complies with multiple industry standards including UL1449, CSA, IEC, VDE, CQC, and RoHS compliance.
- Maximum AC voltage rating of 505 V and DC voltage rating of 670 V for diverse circuit protection.
- Low energy rating of 0.4 J suitable for sensitive electronic circuits.
- Compact size with length of 38.5 mm, thickness and depth of 6.2 mm.
Product Description
Panasonic ERZV14D471 Surge Absorber belongs to the V Series metal oxide varistors designed for effective surge protection in electronic circuits. Featuring a capacitance of 400 pF and a clamping current of 50 A with a Clamping voltage of 1355 V, it offers robust transient voltage suppression. This radial mount varistor is constructed with a 15.5 mm diameter and crimped lead termination style, facilitating secure and efficient mounting on printed circuit boards.
Its operational temperature range extends from -40°C to 85°C, allowing reliable performance across demanding industrial and commercial environments. Rated for a maximum AC voltage of 505 V and a DC voltage of 670 V, it ensures protection against voltage spikes in various applications including power supply lines and surge protection components.
Panasonic ERZV14D471 complies with numerous international safety and quality standards such as UL1449, CSA C22.2 N 269.5, IEC62368-1, VDE IEC61051-1, IEC60950-1 Annex.Q, CQC certifications, and RoHS, confirming its suitability for global use.
This varistor combines compact dimensions with high surge current tolerance up to 6 kA and an energy rating of 0.4 J, making it ideal for protecting sensitive electronics in industrial, laboratory, manufacturing, HVAC, and commercial applications where voltage transient suppression is critical.
High surge current handling capacity suitable for compact installations. Metal oxide varistor with 15.5 mm diameter for reliable performance. Radial mount type with crimped lead termination for easy installation. Operating temperature range from -40°C to 85°C for versatile usage conditions.
Complies with multiple industry standards including UL1449, CSA, IEC, VDE, CQC, and RoHS compliance. Maximum AC voltage rating of 505 V and DC voltage rating of 670 V for diverse circuit protection. Low energy rating of 0.4 J suitable for sensitive electronic circuits.
Compact size with length of 38.5 mm, thickness and depth of 6.2 mm. Pin pitch of 7.5 mm ensures compatibility with standard circuit boards. Explore more Panasonic surge absorbers and varistors on EnvMart to find suitable components for your electrical and electronic surge protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 400 pF.
It can handle a maximum surge current of 6 kA.
The maximum AC voltage rating is 505 V, and the maximum DC voltage rating is 670 V.
The clamping voltage is 1355 V.
The operating temperature range extends from -40°C to 85°C.
The energy rating is 0.4 J, making it suitable for sensitive electronic circuits.
It features a radial mount type with crimped lead termination for easy installation.
The dimensions are 38.5 mm in length, 6.2 mm in thickness, and 6.2 mm in depth.
It has a pin count of 2 and a lead pitch of 7.5 mm.
It complies with multiple standards including UL1449, CSA, IEC, VDE, CQC, and RoHS.
This model is suitable for protecting sensitive electronics in industrial, laboratory, manufacturing, HVAC, and commercial applications.
The diameter of this model is 15.5 mm.
