TE Connectivity 1812 Shielded Wirewound Surface Mount Inductor 2.2 μH ±10 % 380 mA Idc Q50 3613C2R2K

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity 1812 Shielded Wirewound Surface Mount Inductor 2.2 μH ±10 % 380 mA Idc Q50 3613C2R2K

Name: TE Connectivity 1812 Shielded Wirewound Surface Mount Inductor 2.2 μH ±10 % 380 mA Idc Q50 3613C2R2K
Brand: TE Connectivity
SKU: 375460
Price: 0.67 USD
Availability: InStock



Category Surface Mount Inductor Brand TE Connectivity Condition New

Specifications

Country of Origin	Taiwan
Brand	TE Connectivity
Height	3.2mm
Length	4.5mm
Model	3613C2R2K
Depth	3.2mm
Packaging	Tape
Series	3613C
Maximum Operating Temperature	100°C
Minimum Operating Temperature	-30°C
Core Material	Ferrite
Inductance	2.2μH
Standards/Approvals	RoHS
Package/Case	1812
Maximum DC Current	380mA
Pin Count	2
Maximum DC Resistance	700mΩ
Inductance Tolerance	±10 %
Termination Style	Solder
Maximum Self Resonant Frequency	55MHz
Minimum Quality Factor	50
Inductor Construction	Wirewound

Key Features

Compact 1812 package size suitable for automated surface mounting.
Ferrite core construction provides stable inductance and low losses.
Maximum operating temperature of 100°C ensures reliable performance.
Shielded design reduces electromagnetic interference in circuits.
Two-pin solder termination style for secure PCB connection.
Maximum DC resistance of 700 mΩ limits power dissipation.
Inductance Q factor minimum of 50 at 55 MHz self-resonant frequency.
Operating temperature range from -30°C to +100°C supports varied environments.

Product Description

TE Connectivity model 3613C2R2K is a shielded wirewound Surface Mount Inductor designed in the 1812 package size, measuring 4.5 mm in length with 3.2 mm height and depth. Featuring a ferrite core construction, this inductor provides an inductance of 2.2 μH with a tolerance of ±10 %. It supports a maximum DC current of 380 mA and maintains a high quality factor of 50, delivering efficient performance at frequencies up to 55 MHz.

Its shielded design helps minimize electromagnetic interference, making it ideal for compact, automated PCB assembly applications in electronics manufacturing. The inductor operates reliably within a temperature range of -30°C to +100°C, with a maximum DC resistance of 700 milliohms to limit power loss during operation. The solder termination style ensures a secure and durable connection on surface mount boards.

This component complies with RoHS standards, reflecting adherence to environmental directives. Originating from Taiwan, Province Of China, the 3613C series inductors by TE Connectivity are widely used in a variety of industrial and commercial electronic devices requiring stable inductance and resistance to electromagnetic interference.

Compact 1812 size ideal for automated surface mounting. Ferrite core material offers reliable inductance stability. ±10 % inductance tolerance guarantees performance consistency. Maximum operating temperature of 100°C ensures durability.

Shielded structure effectively suppresses EMI. Solder terminations provide secure PCB connections. High quality factor of 50 at 55 MHz frequency. Wide operating temperature range from -30°C to +100°C. RoHS compliance supports environmental safety.

This inductor is suitable for use in industrial electronics, telecommunications, power management, and consumer electronic devices requiring compact, high-performance inductors. Explore the Electronics & Electricals category on EnvMart for more inductors and related components.
