Vishay 1.3 W 33 V Zener Diode Single Through Hole 2-Pin DO-41 BZX85C33-TAP

Free Delivery in India | Lowest Global Shipping Charges

Vishay 1.3 W 33 V Zener Diode Single Through Hole 2-Pin DO-41 BZX85C33-TAP

Name: Vishay 1.3 W 33 V Zener Diode Single Through Hole 2-Pin DO-41 BZX85C33-TAP
Brand: Vishay
SKU: 355773
Price: 0.1 USD
Availability: InStock



Category Zener Diode Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	2.6mm
Length	4.1mm
Model	BZX85C33-TAP
Mount Type	Through Hole
Series	BZX85
Maximum Operating Temperature	175°C
Package Type	DO-41
Minimum Operating Temperature	-55°C
Pay online using	Or choose to pay later via bank transfer
RS Stock No.	708-7925PBrand: VishayManufacturers Part No.: BZX85C33-TAP
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	1.3W
Diode Configuration	Single
Test Current It	8mA
Maximum Reverse Leakage Current	500nA
Nominal Zener Voltage Vz	33V
Zener Type	Voltage Regulator
Maximum Zener Impedance	35Ω

Key Features

This diode features a single-element silicon planar structure for stable voltage regulation.
It supports a maximum test current of 8 mA with low maximum reverse leakage current of 500 nA.
The DO-41 package type offers robust through-hole mounting with 2-pin configuration.
Operating temperature ranges from -55°C to 175°C, suitable for automotive applications compliant with AEC-Q101.
The device has maximum Zener impedance of 35 Ω ensuring efficient voltage regulation.
Compact size with height 2.6 mm and length 4.1 mm fits versatile circuit designs.

Product Description

Vishay BZX85C33-TAP is a single silicon planar power Zener diode designed for voltage regulation applications. It delivers a nominal Zener voltage of 33 V and can dissipate up to 1.3 watts of power. The diode is housed in a standard DO-41 through-hole 2-pin package which is ideal for mounting on printed circuit boards.

This Zener diode features a ±6% tolerance on the Zener voltage, ensuring reliable regulation for stabilising and clipping circuits with high power ratings. It supports a test current of 8 mA and maintains a maximum reverse leakage current of just 500 nA, thereby providing excellent stability and low noise in voltage regulation.

Engineered for robustness, the diode operates across a wide temperature range from -55°C to 175°C and meets the automotive industry standard AEC-Q101, making it suitable for automotive and industrial electronic systems. The maximum Zener impedance of 35 Ω guarantees efficient voltage regulation performance.

Compact physical dimensions with a height of 2.6 mm and a length of 4.1 mm make it adaptable for various electronic designs requiring space-saving and reliable power components. The BZX85 series from Vishay is widely used in stabilising circuits, voltage clamp applications, and protection circuits in industrial, laboratory, automotive, and commercial electronic devices.

This diode features a single-element silicon planar structure for stable voltage regulation. It supports a maximum test current of 8 mA with low maximum reverse leakage current of 500 nA. The DO-41 package type offers robust through-hole mounting with 2-pin configuration.

Operating temperature ranges from -55°C to 175°C, suitable for automotive applications compliant with AEC-Q101. The device has maximum Zener impedance of 35 Ω ensuring efficient voltage regulation. Compact size with height 2.6 mm and length 4.1 mm fits versatile circuit designs.

Choose Vishay Zener Diode BZX85C33-TAP for superior voltage regulation performance in your discrete semiconductor needs. Explore more in the Electronics & Electricals category at EnvMart for this and related components.
