DiodesZetex 2 3.6 V Zener Diode Common Anode 300 mW 5% Surface Mount 3-Pin SOT-23 AZ23C3V6-7-F

DiodesZetex AZ23C3V6-7-F is a precision 3.6 V Zener diode specified as a common anode device, rated at 300 mW maximum power dissipation. It is supplied in the compact 3-pin SOT-23 surface mount package, facilitating efficient PCB mounting in compact circuit designs.

This Zener diode series features two elements per chip providing enhanced electrical characteristics, including a maximum zener impedance of 500 Ω at the test current of 5 mA, with a tightly controlled voltage tolerance of ±5%. The device also exhibits low maximum reverse leakage current of 100 nA, ensuring stable operation under reverse bias conditions.

The operating temperature range from -65°C to 150°C qualifies it for demanding industrial environments, including automotive applications compliant with the AEC-Q101 standard. This high reliability makes the diode suitable for power regulation, voltage reference, and transient voltage suppression in industrial, automotive, and consumer electronics contexts.

The diode's physical dimensions are 3 mm in length and 1.2 mm in height, supporting space-conscious electronic designs. Its ESD suppression Type delivers inherent protection against electrostatic discharge, increasing device longevity.

Nominal Zener voltage: 3.6 V with ±5% tolerance. Maximum power dissipation: 300 mW. Surface mount SOT-23 package, 3-pin configuration. Automotive-grade AEC-Q101 qualification. Operating temperature: -65°C to 150°C. Maximum reverse leakage current: 100 nA.

Test current of 5 mA. Compact size: 3 mm length, 1.2 mm height.

This DiodesZetex Zener diode is ideal for voltage regulation and transient suppression in industrial and automotive electrical systems. It supports robust, space-efficient PCB designs with reliable electrical performance. Browse more Zener Diodes and semiconductor components on EnvMart for your technical and industrial project needs.
