Preci-Dip 800 Series Straight Surface Pin Header, 9 Contact(s), 2.54 mm Pitch, 1 Row, Unshrouded 800-80-009-30-480101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Surface |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 800 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Pay online using | Or choose to pay later via bank transfer |
| Contact Plating | Tin |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
Key Features
- Constructed from fibreglass reinforced polyethylene terephthalate housing for durability.
- Brass contacts with tin plating ensure reliable conductivity and corrosion resistance.
- Designed for surface mounting with solder termination type.
- Supports operating temperatures from -55°C to 125°C for versatile environmental usage.
- Rated for 150 V voltage and 3 A current capacity to handle standard PCB power requirements.
- Unshrouded, straight orientation facilitates easy insertion and connection.
- Complies with UL 94V-0 standards for flammability resistance.
- Manufactured in Switzerland ensuring high quality standards.
Product Description
Preci-Dip 800-80-009-30-480101 is a high-quality PCB pin header from the 800 Series designed for industrial electronic applications, featuring 9 male contacts arranged in a single straight row with a 2.54 mm pitch. Its fibreglass reinforced polyethylene terephthalate housing offers excellent mechanical strength and chemical resistance suitable for demanding environments.
The brass contact pins are tin plated to provide reliable electrical connectivity and resist corrosion over long-term use. This surface mount device uses solder termination, enabling easy and robust attachment to printed circuit boards.
Designed to operate effectively within a temperature range of -55°C to 125°C, this pin header supports a voltage of up to 150 V and current of 3 A, making it suitable for a wide range of power and signal PCB applications in industrial, manufacturing, and electronic equipment.
The unshrouded, straight orientation design of the pin header allows straightforward pin insertion and compatibility with various connector housings, enhancing versatility in PCB assembly layouts.
All materials comply with UL 94V-0 flammability standards, ensuring safety and reliability in electronic device construction. This product is manufactured in Switzerland, reflecting precision engineering and consistent quality control.
Constructed with fibreglass reinforced polyethylene terephthalate housing. Brass contact material with tin plating for corrosion resistance. Supports surface mount technology with solder termination. Operates in harsh environments from -55°C to 125°C.
Rated for 150 V and 3 A electrical performance. Unshrouded, straight male contact pins with 2.54 mm pitch. Single row with 9 contacts tailored for PCB design flexibility. Compliant with UL 94V-0 flammability standards. Manufactured in Switzerland for quality assurance.
This Preci-Dip 800 Series pin header is suitable for electronic manufacturing, industrial equipment assembly, laboratory instrumentation, and other PCB application areas requiring dependable, robust electrical connections. Discover more from Preci-Dip and related PCB connectors at EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a voltage of up to 150 V, making it suitable for standard PCB power requirements.
The current capacity is rated at 3 A, allowing it to handle typical electrical loads in PCB applications.
The contacts are arranged with a pitch of 2.54 mm, which is standard for many PCB connectors.
It features a housing made from fibreglass reinforced polyethylene terephthalate and brass contacts with tin plating for corrosion resistance.
It operates effectively within a temperature range of -55°C to 125°C, suitable for various environmental conditions.
This model has 9 male contacts arranged in a single row, allowing for efficient connection in PCB layouts.
It uses solder termination, which facilitates a secure attachment to printed circuit boards.
This model is unshrouded, which allows for straightforward pin insertion and compatibility with various connector housings.
It complies with UL 94V-0 standards for flammability resistance, ensuring safety in electronic device construction.
It is manufactured in Switzerland, reflecting high quality standards and precision engineering.
This model supports surface mounting, making it suitable for various PCB assembly applications.
It is suitable for electronic manufacturing, industrial equipment assembly, and laboratory instrumentation among other PCB applications.
