Preci-Dip 832 Series Straight Through Hole Pin Header, 18 Contacts, 2 mm Pitch, 2 Row, Unshrouded 832-80-018-10-001101

Preci-Dip 832-80-018-10-001101 is a high quality straight through hole pin header connector from the 832 Series designed for printed circuit board (PCB) applications. Featuring 18 male contacts arranged in two rows with a 2 mm pitch, it offers reliable connectivity in electronic and power circuit assemblies.

This pin header uses brass contact material with tin plating to ensure excellent electrical conductivity and corrosion resistance. The housing is fabricated from fiberglass reinforced polymer, delivering robust mechanical strength and electrical insulation suitable for demanding environments.

The connector supports a current rating of 3 amperes and a maximum voltage of 150 volts, making it suitable for power distribution and signal applications. It functions efficiently within a wide temperature range of -55°C to 125°C, ensuring stability under harsh thermal conditions.

Designed as unshrouded and with through hole mount type, this connector facilitates solder termination with a contact tail length of 2.9 mm, ensuring secure PCB solder joints. Its 0.47 mm pin diameter aligns with standard IC socket connectors for compatibility.

Manufactured in Switzerland, this Preci-Dip product adheres to precise quality standards, though no specific certifications are listed. It is commonly used in electronics manufacturing, instrumentation, industrial control systems, and power electronics modules.

This pin header supports a current rating of up to 3 amperes. Constructed with brass contacts and tin plating for corrosion resistance. Fiberglass reinforced polymer housing offers durability and insulation. Operates at temperatures from -55°C to 125°C for robust performance.

Rated for 150 V maximum operating voltage suitable for power circuits. Unshrouded design with 2 mm pitch in 2 rows for versatile PCB layouts. Through hole mount type with solder termination ensures solid PCB connection. Pin diameter of 0.47 mm with a 2.9 mm tail length for standard PCB assembly.

This Preci-Dip pin header is ideal for use in industrial electronic assemblies, laboratory instrumentation, power connectors for embedded systems, and various manufacturing applications. EnvMart offers this component as a reliable solution for high precision electronic connector needs.
