Molex SPOX Series Straight Through Hole PCB Header 14 Contacts 2.5 mm Pitch 1 Row Shrouded 22-03-5145
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | SPOX |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Contact Plating | Tin |
| Number of Contacts | 14 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.5mm |
Key Features
- Low profile shrouded PCB header ensures secure mating connections.
- Polarization features prevent mismating during assembly.
- Friction lock mechanism maintains secure wire-to-board connections.
- Constructed with nylon housing and brass contacts plated with tin.
- Suitable for through-hole mounting with male solder terminations.
- Supports currents up to 3A and voltage rating of 250V.
- Operates reliably from -40°C up to 105°C maximum temperature.
- Tail pin length is 3.5 mm for secure PCB retention.
Product Description
Molex 22-03-5145 SPOX Series Straight Through Hole PCB Header is a 14-contact PCB connector featuring a 2.5 mm pitch in a low-profile, shrouded, 1-row design. It is engineered for wire-to-board applications requiring reliable and secure electrical connections.
This connector utilizes a nylon housing combined with brass contacts plated with tin to ensure corrosion resistance and durability under industrial conditions. The shrouded design offers polarization to avoid mismating, while the friction lock mechanism provides a stable and secure mating connection during vibration or environmental stress.
The header is designed for through-hole mounting and solders easily to printed circuit boards. It supports up to 3A current and can operate within a temperature range of -40°C to +105°C, suitable for many industrial, automotive, telecommunications, and data communications uses.
The 3.5 mm tail pin length and solder termination type provide a strong, reliable connection to the PCB. This part mates with Molex's SPOX series crimp housings, enabling versatile wire-to-board interconnect solutions.
Low profile shrouded PCB header design. Polarization prevents assembly errors and mismatings. Friction lock ensures secure mating connection. Durable nylon housing with brass tin-plated contacts. Through-hole mount type with male solder termination.
Current rating of 3A and voltage rating of 250V. Operational temperature range of -40°C to 105°C. Compatible with Molex SPOX crimp housings.
This Molex SPOX PCB header is ideal for application in automotive electronics, consumer devices, data communications, industrial equipment, medical instruments, networking hardware, and telecommunications systems. It provides a reliable and robust wire-to-board interconnection solution.
Explore more Molex PCB Headers and connectors in our Electronics & Electricals category at EnvMart for comprehensive industrial-grade components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a current rating of 3A and a voltage rating of 250V.
It features a 2.5 mm pitch and has 14 contacts.
The housing is made of nylon, while the contacts are brass plated with tin for corrosion resistance.
It operates reliably within a temperature range of -40°C to +105°C.
This model is designed for through-hole mounting with male solder terminations.
The shrouded design includes polarization features that prevent mismating during assembly.
The tail pin length is 3.5 mm, providing secure retention on the PCB.
It is suitable for applications in automotive electronics, consumer devices, data communications, industrial equipment, medical instruments, networking hardware, and telecommunications systems.
This connector is designed for wire-to-board applications.
The orientation of this model is straight.
The friction lock mechanism maintains a secure wire-to-board connection, even during vibration or environmental stress.
Yes, it mates with Molex's SPOX series crimp housings, enabling versatile interconnect solutions.
