STMicroelectronics 200 V 120 A Diode Switching 4-Pin ISOTOP STTH20002TV1
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 4mm |
| Brand | STMicroelectronics |
| Height | 9.1mm |
| Length | 38.2mm |
| Model | STTH20002TV1 |
| Width | 25.5mm |
| Mount Type | Panel |
| Series | STTH20002TV |
| Maximum Operating Temperature | 150°C |
| Package Type | ISOTOP |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 4 |
| Maximum Continuous Forward Current If | 120A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Isolated |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 100μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 1kA |
| Maximum Forward Voltage Vf | 1.2V |
| Peak Reverse Recovery Time trr | 50ns |
Key Features
- This diode features a panel mount type with ISOTOP package.
- It supports a maximum continuous forward current of 120 A.
- The peak reverse repetitive voltage rating is 200 V.
- The diode has a switching rectifier type with isolated diode configuration.
- It operates within a temperature range from -55°C to 150°C.
- The peak non-repetitive forward surge current is rated at 1 kA.
- Physical dimensions include a length of 38.2 mm, width of 25.5 mm, height of 9.1 mm and a diameter of 4 mm.
- The maximum forward voltage drop is 1.2 V and peak reverse recovery time is 50 ns.
Product Description
STMicroelectronics STTH20002TV1 switching diode features a robust design tailored for high current rectification in industrial and electronic power applications. With a 200 V peak reverse voltage and a continuous forward current of 120 A, this isolated 4-pin ISOTOP package diode offers reliable switching performance with minimal power loss due to its 1.2 V maximum forward voltage drop.
This diode supports harsh operating conditions, tolerating temperatures from -55°C to 150°C, making it suitable for automotive, industrial manufacturing, power supply units, and other demanding environments requiring efficient switching rectifiers.
The diode construction complies with RoHS standards, ensuring environmentally safe manufacturing and disposability. Its compact dimensions - 38.2 mm length, 25.5 mm width, 9.1 mm height, and 4 mm diameter - allow for space-efficient PCB assembly in panel mount configurations.
This diode features a panel mount type with ISOTOP package. Supports maximum continuous forward current of 120 A. Peak reverse repetitive voltage of 200 V ensures reliability. Isolated diode configuration designed for switching rectifier use.
High surge current tolerance of 1 kA for transient conditions. Designed to operate in a wide temperature range from -55°C to 150°C. Low forward voltage drop of 1.2 V reduces power dissipation. Fast recovery time of 50 ns optimizes switching efficiency.
RoHS compliant for environmental safety. Packed in tubes ready for machine insertion, enhancing production efficiency.
This product is widely employed in electronic component manufacturing, power & connectors distribution, and semiconductor assembly lines. Its specifications allow applications across automotive electronics, power converters, industrial automation, and commercial energy management systems.
Explore more Schottky and switching diodes in the Electronics & Electricals > Semiconductor > Schottky Diodes & Rectifiers category on EnvMart to find compatible components for your projects.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this diode is 120 A.
The peak reverse repetitive voltage rating of this model is 200 V.
It operates within a temperature range from -55°C to 150°C.
The physical dimensions include a length of 38.2 mm, width of 25.5 mm, height of 9.1 mm, and a diameter of 4 mm.
The maximum forward voltage drop is rated at 1.2 V.
The peak non-repetitive forward surge current is rated at 1 kA.
This diode uses an ISOTOP package type.
The peak reverse recovery time is rated at 50 ns.
This diode has a pin count of 4.
Yes, this diode complies with RoHS standards, ensuring environmentally safe manufacturing and disposability.
It has an isolated diode configuration designed for switching rectifier use.
This diode is commonly used in automotive electronics, power converters, industrial automation, and commercial energy management systems.
