Texas Instruments 8-Bit Non-Inverting LVTTL Bus Transceiver, 24-Pin TVSOP SN74LVC8T245DGVR

Texas Instruments SN74LVC8T245DGVR is an 8-bit bus transceiver designed for non-inverting data transmission applications. Packaged in a compact 24-pin TVSOP surface mount package, it operates over a supply voltage range of 1.65V to 3.6V, enabling low power consumption designs primarily in digital logic systems.

The device provides 8 bidirectional channels with 3-state outputs allowing effective bus sharing in embedded systems. It supports LVTTL and TTL input levels, and outputs are compatible with LVCMOS logic levels, making it suitable for a broad range of digital circuits.

With a maximum propagation delay of 23.4 nanoseconds at the specified load, the SN74LVC8T245DGVR supports timing-critical applications. Its operating temperature range from -40°C to 85°C ensures reliable performance in industrial and commercial environments.

Designed with silicon gate CMOS technology, it offers low power dissipation and improved latch-up immunity exceeding 250 mA per JESD 17. Additionally, ESD protection surpasses JESD 22 standards, ensuring robust handling during manufacturing and assembly.

This transceiver is ideal for data bus interfacing in computing, telecommunications, and industrial automation systems requiring level shifting, buffering, or bus driving capabilities.

Features 8 channels for bidirectional data transmission. Non-inverting logic functionality ensures signal integrity. Surface mount design in a compact 24-pin TVSOP package. Maximum propagation delay time of 23.4ns at specified load conditions.

Wide operating temperature range from -40°C to 85°C. Supports 3-state output type for bus applications. Input compatible with LVTTL and TTL levels and output at LVCMOS levels. Maximum supply voltage up to 5.5V with 5V tolerant inputs.

Low power consumption suitable for modern electronic designs. Designed with robust ESD protection beyond JESD 22 standards.

This product is suited for use in electronic manufacturing, laboratory setups, telecommunications hardware, and embedded systems development. It provides a reliable component choice for engineers requiring precise bus transceiver performance.
