Vishay 1-Element Bi-Directional TVS Diode Surface Mount, 2-Pin SMC, 1.5 kW Peak Pulse Power, Model SMCJ7.5CA-E3

Vishay SMCJ7.5CA-E3 is a high-performance 1-Element Bi-Directional Transient Voltage Suppressor (TVS) diode specifically designed for protecting sensitive electronic components against transient voltage surges. Packaged in a 2-pin surface mount SMC format, it delivers a peak pulse power dissipation of 1.5 kW, ensuring robust surge handling capability.

This diode operates bi-directionally, providing symmetrical voltage clipping to prevent damage from overvoltage conditions in both polarities. Its minimum breakdown voltage of 8.33 V and a maximum reverse standoff voltage of 7.5 V give precise voltage suppression while maintaining circuit integrity. The clamping voltage of 12.9 V guarantees rapid voltage curtailment during transient events.

The product is designed for reliable operation in harsh environments, supporting a temperature range from -55°C to 150°C. Its compact SMC package measures 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height, making it suitable for space-constrained PCB layouts.

With a maximum peak pulse current of 116.3 A and integrated ESD protection, the Vishay SMCJ7.5CA-E3 model is ideal for automotive electronics and other demanding industrial applications. This TVS diode meets the AEC-Q101 automotive qualification standard, confirming its suitability for rigorous use cases.

Typically used in industrial, automotive, consumer electronics, and telecommunications circuits, this TVS diode safeguards delicate semiconductor devices from unintended voltage spikes and transient surges induced by switching events, lightning strikes, or electrostatic discharge.

Provides bi-directional surge voltage suppression for sensitive electronics. Compact surface mount SMC package with low profile. High peak pulse power dissipation of 1.5 kW for transient protection. Wide operating temperature range suitable for automotive and industrial use.

Compliant with the automotive AEC-Q101 standard for reliability. 2-pin configuration facilitates ease of PCB integration and assembly. Ensures ESD protection enhancing device lifespan and durability. Precise clamping voltage minimizes risk of downstream component damage.

Designed for applications requiring robust transient voltage suppression. Reliable operation with maximum reverse leakage current of 200 μA. Discover the extensive range of Vishay TVS Diodes and protect your sensitive electronic circuits with confidence at EnvMart.
