Vishay 600 V 3 A Soft Recovery Diode 2-Pin DO-201AD UF5406-E3/54
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 5.3mm |
| Brand | Vishay |
| Height | 5.3mm |
| Length | 9.5mm |
| Model | UF5406-E3/54 |
| Width | 5.3mm |
| Mount Type | Through Hole |
| Series | UFX |
| Maximum Operating Temperature | 150°C |
| Case | DO-201AD Moulding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS-compliant, commercial grade |
| Package Type | DO-201AD |
| Minimum Operating Temperature | -55°C |
| Polarity | Colour band denotes cathode end |
| Terminals | Matte tin-plated leads, solderable per J-STD-002 and JESD 22-B102 E3 suffix meets JESD 201 class 1A whisker test |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 3A |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Diode Configuration | Single |
| Rectifier Type | Soft Recovery |
| Peak Reverse Current Ir | 10μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 150A |
| Maximum Forward Voltage Vf | 1.7V |
| Peak Reverse Recovery Time trr | 75ns |
| Vishay 600V 3A, Silicon Junction Diode, 2-Pin DO-201AD UF5406Brand | Vishay |
Key Features
- The diode features a glass passivated chip junction for reliability.
- It has an ultrafast reverse recovery time of 75 ns.
- The diode offers low forward voltage drop of 1.7 V for efficiency.
- It supports a peak non-repetitive forward surge current of 150 A.
- Designed for high switching efficiency with low switching losses.
- Operates reliably between -55°C to 150°C operating temperature range.
- The package meets UL 94 V-0 flammability rating and RoHS compliance.
- Terminals are matte tin-plated leads, solderable per J-STD-002 standards.
Product Description
Vishay UF5406-E3/54 is a high-quality soft recovery diode rated for 600 V maximum repetitive peak reverse voltage and 3 A continuous forward current. Packaged in a 2-pin DO-201AD through-hole case, this diode is engineered with a glass passivated chip junction delivering excellent reliability and long-term stability.
The ultrafast reverse recovery time of 75 ns reduces switching losses and improves efficiency in high frequency rectification and freewheeling duties, making it suitable for switching mode power supplies, inverters, and consumer electronics.
Its low forward voltage drop of 1.7 V enhances energy efficiency while sustaining a high peak non-repetitive surge current of 150 A, ensuring robust performance under transient conditions.
The diode operates over a wide temperature range from -55°C to 150°C, thus meeting demanding industrial and commercial application requirements. Mechanical construction includes a moulded DO-201AD case compliant with UL 94 V-0 flammability rating, and matte tin-plated leads solderable to industry standards, ensuring ease of assembly and durability.
Glass passivated chip junction. Ultrafast reverse recovery time of 75ns. Low forward voltage drop of 1.7 V. High forward surge capability of 150 A. Wide operating temperature range from -55°C to 150°C. RoHS-compliant, commercial grade packaging.
Matte tin-plated solderable leads. Polarity indicated by cathode color band.
This diode is optimized for high frequency rectification and freewheeling in switching mode converters and inverters across consumer, computer, and telecommunication sectors. With its robust construction and performance, the Vishay UF5406-E3/54 Diode is an ideal choice for electronic component assemblies requiring fast switching and efficient rectification.
Explore more semiconductor components from Vishay and other leading brands on EnvMart for your industrial, laboratory, and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The diode has a maximum repetitive peak reverse voltage of 600 V.
It is rated for a continuous forward current of 3 A.
The reverse recovery time is 75 ns, which helps reduce switching losses.
The forward voltage drop is 1.7 V, enhancing energy efficiency.
It supports a peak non-repetitive forward surge current of 150 A.
This diode operates reliably within a temperature range of -55°C to 150°C.
The diode is packaged in a 2-pin DO-201AD through-hole case.
The terminals are matte tin-plated leads, solderable per J-STD-002 standards.
The case meets the UL 94 V-0 flammability rating.
It is optimized for high frequency rectification and freewheeling in switching mode converters and inverters across consumer, computer, and telecommunication sectors.
The polarity is indicated by a color band that denotes the cathode end.
This diode is RoHS-compliant and meets commercial grade packaging standards.
