Vishay 600 V 3 A Soft Recovery Diode 2-Pin Through Hole DO-201AD UF5406-E3/54

Vishay UF5406-E3/54 is a high-quality soft recovery diode designed for efficient power rectification applications requiring fast switching and low losses. Its maximum continuous forward current of 3 A and peak reverse voltage of 600 V make it ideal for a wide range of industrial and electronic uses, including switching mode power supplies and inverters.

The diode is packaged in a robust 2-pin DO-201AD through-hole format made with moulding compound meeting UL 94 V-0 flammability rating, ensuring long operational life and safety in demanding conditions. The glass passivated chip junction delivers enhanced reliability by protecting the semiconductor junction.

With an ultrafast peak reverse recovery time of 75 ns and a low maximum forward voltage drop of 1.7 V, this diode minimizes switching losses and improves power efficiency in high-frequency rectification scenarios. It features a high forward surge current capability of 150 A, allowing it to withstand transient surges without damage.

Terminals are matte tin-plated to facilitate soldering processes compliant with J-STD-002 and JESD 22-B102. The diode's polarity is clearly indicated by a colour band marking the cathode end, simplifying correct installation during assembly.

Operating temperature range from -55°C to 150°C permits use in environments with extreme temperature variations, enhancing applicability in automotive, consumer electronics, and telecommunications equipment.

This commercial grade diode is RoHS-compliant and carries the E3 suffix conforming to the JESD 201 class 1A whisker test, demonstrating adherence to industry quality and reliability standards.

Delivers ultrafast reverse recovery time for efficient switching performance. Glass passivated chip junction ensures durability and reliability. Low forward voltage drop minimizes power loss during operation. High forward surge current capability supports transient events.

Matte tin-plated leads ensure excellent solderability per industry standards. Operating temperature range from -55°C to 150°C suitable for harsh environments. Compact DO-201AD package with dimensions 9.5 mm length and 5.3 mm diameter.

Colour band on casing denotes cathode end for correct polarity identification. RoHS-compliant commercial grade with E3 suffix meeting JESD 201 class 1A whisker test. Ideal for industrial, telecommunications, consumer electronics, and automotive applications demanding reliable ultrafast rectifiers.
