STMicroelectronics Schottky Diode 100 V 8 A Through Hole TO-220AC STPS8H100D
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 9.3mm |
| Length | 10.4mm |
| Model | STPS8H100D |
| Width | 4.6mm |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-220AC |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 8A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 4.5μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 250A |
| Maximum Forward Voltage Vf | 0.56V |
Key Features
- This diode features a TO-220AC package ensuring easy mounting.
- Reverse repetitive voltage rating of 100 V provides high voltage endurance.
- Maximum forward voltage of 0.56 V results in low power loss.
- Designed for operating temperatures from -65°C to 175°C.
- Peak non-repetitive forward surge current rating of 250 A enhances transient current handling.
- Low peak reverse current of 4.5 µA helps improve efficiency.
- The single Schottky diode configuration ensures fast switching.
- Non-automotive standard certified component suitable for general industrial use.
Product Description
STMicroelectronics STPS8H100D is a high-performance Schottky diode designed for power electronics applications requiring low forward voltage drop and fast switching capabilities. Packaged in a durable TO-220AC housing, this 2-pin diode provides a maximum continuous forward current of 8 A and a peak reverse repetitive voltage of 100 V, making it suitable for use in power rectification and freewheeling diode applications in industrial and electronic assemblies.
The diode’s maximum forward voltage of 0.56 V leads to reduced conduction losses and improved overall efficiency in power circuits. It operates reliably in extreme temperature conditions from -65°C up to 175°C, thus meeting the demands of industrial environments with varying thermal challenges.
Its peak non-repetitive forward surge current rating of 250 A allows the component to handle high transient load currents without damage. Meanwhile, the low peak reverse current of 4.5 microamperes underscores its efficiency and low leakage characteristics.
With physical dimensions of 10.4 mm length, 4.6 mm width, and 9.3 mm height, and the through-hole mount type, the STPS8H100D is easily integrated into printed circuit boards for discrete semiconductor applications.
This Schottky diode is widely used in power supplies, voltage clamping circuits, reverse polarity protection, and other power conversion applications within the electronics manufacturing and industrial automation sectors.
This diode features a TO-220AC package ensuring easy mounting. Reverse repetitive voltage rating of 100 V provides high voltage endurance. Maximum forward voltage of 0.56 V results in low power loss. Designed for operating temperatures from -65°C to 175°C.
Peak non-repetitive forward surge current rating of 250 A enhances transient current handling. Low peak reverse current of 4.5 µA helps improve efficiency. Single Schottky diode configuration ensures fast switching. Compact dimensions suitable for PCB integration.
Non-automotive standard component for general industrial use. Explore more STMicroelectronics Schottky Diodes and discrete semiconductors on EnvMart for reliable and efficient power management solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the STPS8H100D is 8 A.
This model has a peak reverse repetitive voltage rating of 100 V.
The maximum forward voltage of this diode is 0.56 V.
It is designed to operate within a temperature range of -65°C to 175°C.
The peak non-repetitive forward surge current rating is 250 A.
The diode is packaged in a TO-220AC housing, suitable for through-hole mounting.
The physical dimensions are 10.4 mm in length, 4.6 mm in width, and 9.3 mm in height.
The peak reverse current is 4.5 µA, indicating low leakage characteristics.
It uses a single Schottky diode configuration, which allows for fast switching.
This diode is commonly used in power supplies, voltage clamping circuits, and reverse polarity protection applications.
The STPS8H100D is manufactured in India.
This model has a pin count of 2.
