Vishay 100 V 70 A Standard Recovery Switching Diode 2-Pin DO-203AB VS-70HFR10
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 17.4mm |
| Brand | Vishay |
| Height | 22.9mm |
| Length | 20.02mm |
| Model | VS-70HFR10 |
| Width | 17.35mm |
| Mount Type | Screw |
| Series | VS-70HF |
| Maximum Operating Temperature | 180°C |
| Package Type | DO-203AB |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 70A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Stud Anode |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 15mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 1.3kA |
| Maximum Forward Voltage Vf | 1.35V |
| Vishay 100 V 70 A Diode Switching 2-Pin DO-203ABBrand | Vishay |
Key Features
- Maximum continuous forward current of 70 A ensures high current capacity.
- Peak reverse repetitive voltage rating of 100 V for reliable operation.
- Compact industrial-standard DO-203AB package with 2 pins for screw mounting.
- Operates between -65°C and a maximum of 180°C temperature range.
- Peak non-repetitive forward surge current capability of 1.3 kA for transient loads.
- Maximum forward voltage of 1.35 V for efficient switching performance.
- Stud anode diode configuration suitable for robust applications.
- Applications include power electronics, industrial switching, and rectifier circuits.
Product Description
Vishay VS-70HFR10 is a standard recovery switching diode designed for industrial and power semiconductor applications. It supports a maximum continuous forward current of 70 A with a peak reverse repetitive voltage of 100 V, encapsulated in a durable DO-203AB 2-pin package with screw mount capability.
This diode features a stud anode configuration and provides reliable switching performance with a maximum forward voltage drop of 1.35 V, enabling efficient power management in circuits.
Operating temperature range from -65°C to 180°C allows use in demanding industrial environments with high thermal endurance requirements.
The diode withstands peak non-repetitive forward surge currents up to 1.3 kA, making it suitable for transient overcurrent conditions typical in industrial power electronics, rectifiers, and switching regulators.
Its mechanical dimensions of approximately 22.9 mm height, 20.02 mm length, 17.35 mm width, and 17.4 mm diameter ensure compatibility with standard industrial assemblies. Maximum continuous forward current of 70 A. Peak reverse repetitive voltage of 100 V.
2-pin DO-203AB screw mount package. Operating temperature range from -65°C to 180°C. Peak non-repetitive surge current of 1.3 kA. Maximum forward voltage of 1.35 V. Stud anode diode configuration. Robust mechanical dimensions for industrial use.
This Vishay switching diode is well-suited for industrial, manufacturing, power management, and electronic assembly applications requiring a reliable, high-current diode for rectification and switching.
Browse the Electronics & Electricals category on EnvMart for more semiconductor and Diode solutions from Vishay and other leading brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay VS-70HFR10 diode is 70 A.
This model has a peak reverse repetitive voltage rating of 100 V.
The operating temperature range for the VS-70HFR10 is from -65°C to a maximum of 180°C.
It is encapsulated in a DO-203AB package with a screw mount capability.
The maximum forward voltage drop for the Vishay VS-70HFR10 is 1.35 V.
This model can withstand a peak non-repetitive forward surge current of up to 1.3 kA.
The dimensions are approximately 22.9 mm in height, 20.02 mm in length, 17.35 mm in width, and a diameter of 17.4 mm.
It features a stud anode diode configuration suitable for robust applications.
This diode is suitable for power electronics, industrial switching, and rectifier circuits.
The diode has a pin count of 2.
The peak reverse current for the Vishay VS-70HFR10 is rated at 15 mA.
The country of origin for this diode is India.
