Molex Sabre Series Right Angle Through Hole PCB Header, 2 Contacts, 7.49 mm Pitch, 1 Row, Shrouded 43160-3102

Molex 43160-3102 Sabre Series Right Angle Through Hole PCB Header is a high-quality electronic connector component designed for industrial and commercial electronic assemblies. It features 2 male contacts arranged in a single row with a 7.49 mm pitch and a 7.5 mm row pitch. This PCB header has a shrouded housing made from high temperature thermoplastic, providing excellent insulation and protection for the contacts.

The connector supports current up to 18 amperes at voltages up to 600 volts, making it suitable for robust power transmission in electronic devices. The brass contacts are plated with tin to resist corrosion, and the termination type is solder, which ensures reliable attachment to printed circuit boards. This right angle orientation header has a tail pin length of 3.81 mm designed for through hole mounting.

Operating temperature ranges from -40°C to 75°C, enabling usage in a variety of environmental conditions including industrial, laboratory, and manufacturing settings. The shrouded design provides positive locking with an audible click, ensuring safe and secure mating connections while preventing accidental disconnects. This connector is ideal for wire-to-board applications and supports wiring with 14 to 18 AWG wire gauges.

Featuring robust construction and compliance with UL standards, although no specific approvals are indicated, this PCB header from the Molex Sabre Series is engineered for lasting performance in high current applications. It is well suited for electronics manufacturing, power connector assemblies, and applications requiring dependable signal and power transmission.

Constructed with a high temperature thermoplastic housing for durability. Right angle orientation with a single row of 2 male contacts. Rated for 18A current at up to 600V voltage for high power applications. Brass contacts plated with tin for corrosion resistance and longevity.

Through hole mounting with solder termination ensures secure PCB attachment. Operating temperature range from -40°C to 75°C for varied environments. Tail pin length of 3.81 mm allows accurate PCB insertion. Shrouded design offers protective insulation and positive locking mating.

Ideal for wire-to-board connector system in industrial electronic applications. Suitable for manufacturing, electronics assembly, and power distribution systems. Explore similar PCB connectors and headers at EnvMart for diverse industrial needs.
