Molex Sabre Series Straight Through Hole PCB Header, 5 Contact, 7.49 mm Pitch, 1 Row, Shrouded 43160-2105

Molex 43160-2105 Sabre Series Straight Through Hole PCB Header is a high-quality electronic connector designed to provide secure and reliable connections on printed circuit boards. Featuring 5 brass male contacts with tin plating, this PCB header supports high current applications up to 18A and voltage ratings up to 600V. The connector is housed in durable high temperature thermoplastic, providing excellent mechanical strength and insulation.

This connector is constructed in a single row with a 7.49 mm pitch between contacts, ideally suited for wire-to-board connections via through-hole mounting. The male contacts feature a 3.81 mm tail pin length for secure soldering, with a shrouded design that ensures correct polarity and mating reliability. It operates reliably across a broad temperature range of -40°C to 75°C, making it suitable for demanding industrial and commercial electronic environments.

The Sabre Series connectors by Molex feature positive locking casings that produce an audible click upon mating, which prevents accidental disconnections during operation or maintenance. This product complies with relevant UL and CSA standards, supporting safety and quality in critical electrical and electronic systems.

Typical applications include power connectors in industrial machinery, electronic components in manufacturing equipment, and other PCB assembly uses where robustness and current capacity are important. The component is specially designed to facilitate ease of installation and to maintain long-term electrical performance.

Packaged for insertion directly into machinery, these connectors help improve production efficiency and system reliability. Whether for industrial electronics, laboratory instruments, or advanced manufacturing processes, this PCB header from Molex exemplifies quality and performance.

Features a shrouded housing for enhanced connector protection and proper mating. Suitable for wire-to-board connection using through-hole mounting. Constructed with brass contacts plated with tin for reliable conductivity.

Can operate safely with currents up to 18A and voltages up to 600V. Designed for operating temperatures from -40°C to 75°C. Includes 3.81 mm tail pin length for secure solder termination. Housing made of high temperature thermoplastic ensuring durability.

Single row, straight orientation design simplifies PCB layout and assembly. Positive locking casings prevent accidental disconnection with audible click. Suitable for use in industrial electronics, power supply, and PCB applications.
