Molex Sabre Series Right Angle Through Hole PCB Header 2 Contact, 7.49 mm Pitch, 1 Row, Shrouded 43160-3102
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 18A |
| Mount Type | Through Hole |
| Housing Material | High Temperature Thermoplastic |
| Contact Material | Brass |
| Series | Sabre |
| Termination Type | Solder |
| Maximum Operating Temperature | 75°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 7.49mm |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.81mm |
| Row Pitch | 7.5mm |
Key Features
- Supports current up to 18A for high power applications.
- Constructed with high temperature thermoplastic housing for durability.
- Brass contacts plated with tin ensure reliable conductivity and corrosion resistance.
- Designed as a through-hole mount with male contacts and solder termination for PCB integration.
- Operates in temperatures from -40°C to 75°C, suitable for varied industrial environments.
- Shrouded casing offers positive locking with audible click to prevent accidental disconnection.
- Compliant with UL E29179 and UL1950 standards, ensuring safety and quality.
Product Description
Molex 43160-3102 Sabre Series Right Angle Through Hole PCB Header is designed to provide reliable wire-to-board connections with high current handling up to 18A and a voltage rating of 600V. The product features a single row of 2 male contacts spaced at 7.49 mm pitch and housed in a shrouded casing made from high temperature thermoplastic, enhancing durability and insulation.
This PCB header has a right angle orientation, facilitating compact PCB mounting with a tail pin length of 3.81 mm suitable for solder termination. Its brass contact material coupled with tin plating provides excellent conductivity and corrosion resistance to maintain performance over long service life.
Engineered for industrial, electronics manufacturing, and power distribution applications, it operates reliably in temperature ranges between -40°C and 75°C. The positive locking, polarized shrouded casing design prevents accidental disconnections and ensures correct mating of connectors.
While not carrying specific certifications, the header meets UL E29179 and UL1950 and CSA LR19980 approval standards, confirming compliance with industry safety requirements. This 43160-3102 series connector is ideal for applications requiring robust, reliable PCB connections with secure mechanical and electrical integrity.
Supports high current up to 18A and 600V rating for power circuits. Durable high temperature thermoplastic housing ensures long-term reliability. Right angle orientation saves PCB space and facilitates integration. Male brass contacts with tin plating for stable electrical connections.
Shrouded design with positive locking prevents mating errors and accidental unplugging. Compatible with wire-to-board connection systems and through-hole mounting technology. Operates within -40°C to 75°C for broad environment usability.
Suitable for industrial, manufacturing, and power electronics applications. Conforms to UL and CSA standards for safety and quality assurance. Explore the extensive range of PCB Headers and connectors available at EnvMart for your electronic and industrial connectivity needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a maximum current rating of 18A, making it suitable for high power applications.
The voltage rating for this model is 600V, which is appropriate for power circuits.
The contacts are spaced at a pitch of 7.49 mm, allowing for compact PCB designs.
It features a housing made from high temperature thermoplastic and brass contacts plated with tin for reliable conductivity and corrosion resistance.
This PCB header operates reliably within a temperature range of -40°C to 75°C, suitable for various industrial environments.
It is designed for through-hole mounting, with male contacts suitable for solder termination on the PCB.
Yes, it features a shrouded casing that provides positive locking and prevents accidental disconnection.
This model has 2 male contacts arranged in a single row.
The tail pin length is 3.81 mm, which is suitable for soldering to the PCB.
It is compliant with UL E29179 and UL1950 standards, confirming its adherence to safety and quality requirements.
This model is engineered for industrial, electronics manufacturing, and power distribution applications, providing reliable wire-to-board connections.
It supports a wire-to-board connection system, making it versatile for various electronic applications.
