Texas Instruments Voltage Level Shifter Bus Transceiver 1 Voltage Level 6-Pin SOT-23 SN74LVC1T45DBVT

Texas Instruments SN74LVC1T45DBVT is a voltage level shifter bus transceiver designed for efficient bi-directional data communication between different voltage levels. Packaged in a compact 6-pin SOT-23 surface mount form factor, this IC operates robustly over a supply voltage range from 1.65 V to 3.6 V, with tolerance up to 5.5 V.

With a maximum propagation delay of 4.4 ns, it provides high-speed switching suitable for advanced electronic applications. The device supports 3-state output functionality, facilitating bus control and line isolation in complex circuit designs.

This transceiver IC handles output currents of ±32 mA, making it compatible with a variety of logic families by translating between LVTTL/TTL inputs and LVCMOS outputs. Its operating temperature range of -40°C to 85°C ensures reliable performance in diverse industrial, laboratory, and commercial environments.

The SN74LVC1T45DBVT is part of Texas Instruments' renowned 74LVC family of low-voltage CMOS logic ICs, utilizing advanced silicon gate CMOS technology optimized for power efficiency at 3.3 V operation.

This product finds applications in electronic component assemblies requiring voltage level translation, such as embedded systems, communication interfaces, and power management circuits.

Operates over a voltage range of 1.65 to 3.6 V. Bi-directional bus transceiver functionality for flexible data communication. Compact 6-pin SOT-23 surface mount package. Maximum propagation delay of 4.4 nanoseconds for fast response.

Tolerant to a maximum supply voltage of 5.5 V. Supports output currents of ±32 mA. Compatible input and output logic standards (LVTTL/TTL and LVCMOS). Operating temperature from -40°C to 85°C suitable for industrial use.

Height 1.15 mm and length 2.9 mm dimensions for space-constrained designs. 3-state output enables complex bus architectures and control.

This voltage level shifter is ideal for laboratory equipment design, industrial control systems, telecommunications, and other electronics manufacturing applications. Explore more products in the Semiconductor Voltage Level Shifter category on EnvMart for complementary components.
