onsemi 2-Input AND Logic Gate, 14-Pin SOIC, CMOS HC Logic Family MM74HC08M

onsemi MM74HC08M 2-Input AND Logic Gate is a high-performance device featuring CMOS technology with the HC logic family in a compact 14-pin SOIC package. It is designed to deliver fast switching speeds comparable to LS-TTL gates while maintaining the low power consumption typical of CMOS circuits.

This logic gate device has buffered outputs to enhance noise immunity and is capable of driving up to 10 LS-TTL loads, making it suitable for complex digital circuit applications. The input protection includes internal diode clamps to VCC and ground, preventing damage from static discharge.

The MM74HC08M operates within a wide supply voltage range from 2V to 6V and supports a broad operating temperature range of -40°C to 85°C, ensuring stable function in diverse environments. Its typical propagation delay times are 7 ns (tPHL) and 12 ns (tPLH), facilitating high-speed digital signal processing.

Key electrical characteristics include a maximum output current of 5.2 mA for both high and low levels and a very low quiescent current consumption of 2 μA at room temperature. This model does not feature Schmitt Trigger inputs.

Buffered outputs provide robust noise immunity and loading capacity. Internal diode clamps protect inputs from static damage. Allows direct replacement and pin compatibility with the 74LS logic family. Compact 14-pin SOIC packaging suited for surface mount technology.

Low power consumption enables energy-efficient circuit designs. Reliable performance across extended temperature and voltage ranges.

This MM74HC08M Logic Gate is widely used in industrial, electronic, and embedded system designs where dependable and fast digital logic functions are essential. It is ideal for applications in digital logic circuits, signal processing, and control systems.
