onsemi 400 V 3 A General Purpose Diode Surface Mount DO-214AB Package S3G

onsemi S3G is a general purpose diode designed for use in diverse electronic components and power applications. This diode features a robust surface mount DO-214AB (SMC) package with 2 pins, allowing easy integration into modern circuit boards with space-saving footprint. Rated for 400 V peak reverse repetitive voltage and 3 A maximum continuous forward current, it provides reliable rectification for various power supply, switching, and protection circuits.

The diode's maximum forward voltage drop of 1.2 V minimizes power loss during conduction, improving system efficiency. Its 100 A peak non-repetitive forward surge current rating ensures it can withstand transient surges typically encountered in industrial and commercial power environments. The operating temperature range between -55°C and 150°C guarantees stable performance in harsh ambient conditions.

With a fast peak reverse recovery time of 2.5 microseconds, the S3G diode supports efficient switching in power electronics. Dimensionally, the compact 7.15 mm length, 6.25 mm width, and 2.75 mm height are suitable for dense PCB layouts. This single configuration diode is ideal for use in electronic assemblies requiring general purpose rectification, including power supplies, motor control, and automotive electronics.

The diode supports a maximum continuous forward current of 3 amperes. It has a peak reverse repetitive voltage rating of 400 volts. The package is a compact surface mount DO-214AB (SMC) type with 2 pins. Maximum forward voltage drop is 1.2 volts, ensuring efficient conduction.

Peak non-repetitive forward surge current is 100 amperes for transient conditions. Operating temperature ranges from -55°C to 150°C for robust performance. The device features a peak reverse recovery time of 2.5 microseconds for switching efficiency.

Dimensions include length 7.15 mm, width 6.25 mm, and height 2.75 mm. The diode is a single configuration general purpose rectifier ideal for electronic and industrial applications.

This diode is widely used in industrial, laboratory, electronic manufacturing, and power management systems, providing dependable rectification and protection. It supports applications in power supplies, automotive electronics, motor drives, and industrial control circuits.
