| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 0.47mm |
| Length | 1mm |
| Model | BZX8850S-C36-QYL |
| Mount Type | Surface |
| Series | BZX8850S |
| Maximum Operating Temperature | 150°C |
| Working voltage range | nominal 1.8 V to 75 V |
| Package Type | DFN1006BD-2 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 365mW |
| Diode Configuration | Single |
| Test Current It | 50μA |
| Maximum Reverse Leakage Current | 50nA |
| Nominal Zener Voltage Vz | 36V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 350Ω |
| Typical Voltage Temperature Coefficient | 30.4mV/K |
Nexperia BZX8850S-C36-QYL is a precision Zener diode designed for reliable voltage regulation in demanding industrial and electronic applications. Featuring a nominal Zener voltage of 36 V and a maximum power dissipation of 365 mW, this single element surface mount diode excels in low-power scenarios.
Encapsulated in an ultra-small DFN1006BD-2 package with side-wettable flanks, it ensures superior solder joint reliability and facilitates automated assembly processes. The device operates safely within a temperature range of -55°C to 150°C, making it suitable for harsh environments including automotive and portable electronic devices.
With a test current of 50 µA and ±5% voltage tolerance, it provides precise voltage regulation with minimal power consumption, ideal for low bias applications. Its maximal Zener impedance of 350 Ω and minimal reverse leakage current of 50 nA further enhance performance stability and efficiency.
The BZX8850S-C36-QYL is certified to AEC-Q101 automotive standards, underscoring its robustness and reliability for automotive electronics and other high-reliability systems in manufacturing, industrial controls, and instrumentation.
This diode is used to maintain fixed voltage levels in circuits and protects against voltage spikes. Its compact size and surface mount design facilitate integration into dense printed circuit boards. Applications include electronic, manufacturing, industrial control, automotive systems, and portable battery-powered devices.
The package dimensions are designed to optimize space without compromising thermal performance. Engineered for low current draw, enhancing energy efficiency in portable and battery-powered systems. The automotive-grade qualification expands its use to critical vehicle electronics requiring stringent quality and reliability.
Choose Nexperia BZX8850S-C36-QYL for effective, reliable, and efficient voltage regulation within your semiconductor and electronic component requirements. Explore more components like this in our Electronics & Electricals category on EnvMart.
Explore more products in our Zener Diodes category.
