Nexperia Bi-Directional ESD Protection Diode DFN2510D, 6V Breakdown, 7A Peak Pulse, USB 3.2 and HDMI Interface PESD4USB5B-TTS

The Nexperia PESD4USB5B-TTS is a high-performance bi-directional ESD protection diode engineered to safeguard critical electronic interfaces such as USB 2.0, SuperSpeed USB 3.2 at 10 Gigabits per second, HDMI 2.0, DisplayPort, eSATA, and LVDS against electrostatic discharge events. Its design utilizes a DFN2510D surface mount package with extremely low line capacitance of only 0.5 picofarads per channel, enabling outstanding signal integrity for high-speed data transmissions.

This diode features a minimum breakdown voltage of 6V and a maximum reverse stand-off voltage of 5V, ensuring reliable protection without interference. The device can absorb peak pulse currents up to 7 amps, with a clamping voltage of 5.5V for energy dissipation during ESD events.

With an operational temperature rating from -65°C to 150°C, the PESD4USB5B-TTS is suitable for demanding industrial and automotive environments. It meets industry-standard IEC 61000-4-2 electrostatic discharge immunity requirements and automotive AEC-Q101 qualification, making it highly trustworthy in automotive applications including infotainment systems, AV monitors, and automotive camera modules.

Its compact 2.5mm length, 1.0mm height, and 0.75mm width physical dimensions allow space-efficient PCB designs. The device supports matched 0.5 mm trace spacing and side-wettable flanks, facilitating easy assembly and improved solder joint reliability.

Provides high-efficiency bi-directional ESD protection for sensitive data lines. Ensures minimal signal distortion with low capacitance of 0.5 pF per channel. Withstands transient currents up to 7A for secure energy absorption.

Automotive grade reliability with AEC-Q101 certification. Compact surface mount package (DFN2510D) suitable for space-constrained designs. Wide operating temperature range from -65°C to 150°C. Compatibility with multiple high-speed data interfaces such as HDMI and USB3.2.

Engineered for infotainment systems, automotive displays, and communication buses.

This product fits within the Electronics & Electricals category, specifically in the Semiconductor branch under ESD Protection Diodes. It is ideal for use in industrial, automotive, and consumer electronics manufacturing and maintenance.
