| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Model | PDTC123JQB-QZ |
| Mount Type | Surface |
| Series | PDTC123J |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN1110D-3 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | 50V |
| Minimum DC Current Gain hFE | 100 |
| Transistor Polarity | NPN |
| Maximum Emitter Base Voltage VEBO | 5V |
| Maximum Collector Base Voltage VCBO | 50V |
| Automotive Standard | AEC-Q101 |
| Maximum DC Collector Current Idc | 100mA |
| Transistor Configuration | NPN |
| Maximum Transition Frequency ft | 230MHz |
Nexperia PDTC123JQB-QZ resistor-equipped NPN transistor is designed for digital and automotive applications requiring reliable switching with high integration. It features a maximum DC collector current of 100 mA and collector-emitter voltage of 50 V packaged in an ultra-small 3-pin DFN1110D-3 surface mount device with a low profile of 0.5 mm.
The integrated resistors simplify circuit design by reducing external component count and lowering manufacturing costs. High minimum DC current gain of 100 and a maximum transition frequency of 230 MHz enable efficient switching and amplification performance under varying loads.
With a wide operating temperature range of - 55°C to 150°C, this transistor meets rigorous automotive qualification requirements including AEC-Q101. The package features side-wettable flanks suitable for automated optical inspection ensuring quality assurance in high-volume production.
Typical uses include controlling integrated circuit inputs, switching loads in digital systems, and serving as a cost-effective alternative to BC857 series transistors. Its compact form factor and embedded resistors make it an excellent choice for space- and cost-sensitive applications in industrial, automotive, consumer electronics, and manufacturing environments.
100 mA DC collector current capability. 50 V maximum collector-emitter voltage rating. Compact 3-pin DFN1110D-3 surface mount package. Resistor equipped to reduce total component count. High gain and fast transition frequency for efficient switching.
Wide temperature operation suitable for automotive use. RoHS compliant and AEC-Q101 automotive standard qualified. Designed for digital and automotive switching applications. Explore the Nexperia Bipolar Transistors category at EnvMart for integrated and discrete semiconductor solutions optimized for high-performance electronics and industrial use.
