Renesas Electronics Programmable Timer Circuit ICM7555IBAZ, 1 Internal Timer, 8-Pin SOIC, 2-18 V Supply, 1 MHz ICM Series

Renesas Electronics ICM7555IBAZ is a high-performance programmable timer circuit designed for versatile timing and frequency generation in electronic applications. Packaged in an 8-Pin SOIC surface mount package, this device integrates a single internal timer operating up to 1 MHz frequency, making it suitable for precise pulse generation and timing delay circuits.

With a wide supply voltage range of 2 to 18 volts, it adapts to various power supply conditions with stable operation. The device operates reliably within an ambient temperature range from -25°C to 85°C, ensuring robustness for general-purpose electronics environments.

This programmable timer IC is compact with dimensions of 5 mm in length and 1.5 mm in height, designed for space-efficient printed circuit board layouts. It does not adhere to automotive standards but is suitable for diverse consumer electronics, industrial controls, and timing applications.

The ICM7555IBAZ series is part of the trusted ICM family from Renesas Electronics, known for high stability and timing accuracy. Typical applications include clock generation, timers, pulse-width modulation, and frequency control circuits.

Operates on a supply voltage from 2 V to 18 V. Packages in surface mount 8-Pin SOIC. Contains 1 internal timer for customizable timing functions. Supports operating temperatures from -25°C to 85°C. Offers compact dimensions suitable for dense PCB designs.

Manufactured in China. General purpose timer with 1 MHz frequency capability.

This component is extensively used in electronics design, industrial instrumentation, and electronic prototyping. Browse more Timer Circuits on EnvMart for related components and accessories.
