Vishay 150 V 200 A Surface Mount Schottky Diode 3-Pin TO-240AA VS-VSKDS409/150
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 29mm |
| Length | 92mm |
| Model | VS-VSKDS409/150 |
| Width | 22.6mm |
| Mount Type | Surface |
| Series | VSX |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-240AA |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 200A |
| Peak Reverse Repetitive Voltage Vrrm | 150V |
| Diode Configuration | Series |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 85mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 20kA |
| Maximum Forward Voltage Vf | 1.33V |
Key Features
- Provides low forward voltage drop for efficient power conversion.
- Equipped with fast switching capabilities for reduced power loss.
- Designed to operate reliably between -55°C and 175°C.
- Offers a peak non-repetitive forward surge current of 20 kA for transient conditions.
- Constructed with 3 pins for secure mounting and operation.
- Compact dimensions with 92 mm length, 29 mm height, and 22.6 mm width.
- Suitable for industrial and electronic component applications requiring high current diodes.
- Does not comply with automotive standards but is ideal for power and semiconductor uses.
Product Description
Vishay VS-VSKDS409/150 is a high-performance Schottky diode designed with a 3-pin TO-240AA package suitable for surface mount applications. It supports a maximum continuous forward current of 200 A and a peak reverse repetitive voltage of 150 V, making it ideal for power electronics and fast switching applications.
The diode features a low forward voltage drop of 1.33 V, contributing to energy efficiency in circuits and minimal power loss. Its specification includes a peak non-repetitive forward surge current of 20 kA, able to withstand transient surges effectively.
Operating temperature ranges from -55°C to 175°C ensure reliable function in demanding industrial environments. The diode has a compact size, with physical dimensions including a length of 92 mm, height of 29 mm, and width of 22.6 mm, facilitating its use in various power modules and electronic systems.
These Schottky rectifiers are engineered for applications requiring fast switching and low power loss, commonly utilized in industrial power supplies, manufacturing equipment, and electronic component assemblies.
Provides low forward voltage drop for efficient power conversion. Equipped with fast switching capabilities for reduced power loss. Designed to operate reliably between -55°C and 175°C. Offers a peak non-repetitive forward surge current of 20 kA for transient conditions.
Constructed with 3 pins for secure mounting and operation. Compact dimensions with 92 mm length, 29 mm height, and 22.6 mm width. Suitable for industrial and electronic component applications requiring high current diodes.
Does not comply with automotive standards but is ideal for power and semiconductor uses.
This Vishay Schottky diode exemplifies industry-leading semiconductor technology, delivering robust performance for applications in electronics manufacturing, HV power equipment, and semiconductor rectification systems. EnvMart presents this high-quality Diode for demanding industrial environments.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for the Vishay VS-VSKDS409/150 Schottky diode is 200 A.
This model has a peak reverse repetitive voltage rating of 150 V.
The diode has dimensions of 92 mm in length, 29 mm in height, and 22.6 mm in width.
It is designed to operate reliably within a temperature range of -55°C to 175°C.
The maximum forward voltage drop for this Schottky diode is 1.33 V.
The diode can withstand a peak non-repetitive forward surge current of 20 kA.
This model features a 3-pin configuration for secure mounting and operation.
The diode is packaged in a TO-240AA type, suitable for surface mount applications.
It is suitable for industrial power supplies, manufacturing equipment, and electronic component assemblies that require high current diodes.
This diode is a Schottky rectifier, known for its fast switching capabilities and low power loss.
The peak reverse current for the Vishay VS-VSKDS409/150 is rated at 85 mA.
No, this diode does not comply with automotive standards but is designed for power and semiconductor applications.
