onsemi 650 V 40 A Silicon Carbide Schottky Diode TO-220 3-Pin FFSP4065BDN-F085
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 9.4mm |
| Length | 10.67mm |
| Model | FFSP4065BDN-F085 |
| Width | 4.7mm |
| Mount Type | Through Hole |
| Series | FFSP |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-220 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | Pb-Free, RoHS |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 40A |
| Peak Reverse Repetitive Voltage Vrrm | 650V |
| Diode Configuration | 2x Common Cathode Pair |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 160A |
| Peak Non-Repetitive Forward Surge Current Ifsm | 882A |
| Maximum Forward Voltage Vf | 2.4V |
Key Features
- Silicon Carbide technology provides superior switching performance and excellent thermal efficiency.
- Maximum continuous forward current of 40 amperes ensures robust power handling.
- Peak reverse repetitive voltage up to 650 volts for reliable operation in power circuits.
- Compact TO-220 3-pin package suitable for through-hole mounting.
- Maximum junction temperature rating of 175°C allows high temperature endurance.
- Features low forward voltage drop of 2.4 volts to reduce power losses.
- High surge current capacity up to 882 amperes for transient conditions.
- Positive temperature coefficient and ease of paralleling simplify thermal management.
Product Description
onsemi FFSP4065BDN-F085 is a high-performance Silicon Carbide (SiC) Schottky Diode optimized for power electronics applications requiring high efficiency, high reliability, and superior thermal characteristics. This device is housed in a compact TO-220 3-pin through-hole package, making it suitable for industrial and automotive power systems.
Leveraging Silicon Carbide technology, the diode exhibits no reverse recovery current and temperature-independent switching, which results in reduced electromagnetic interference, increased switching frequencies, and enhanced power density. These advantages contribute to overall system size and cost reductions.
The diode supports a maximum continuous forward current of 40 A and can withstand a peak reverse repetitive voltage of 650 V, making it ideal for high-power applications including hybrid electric vehicle (HEV) and electric vehicle (EV) onboard chargers and DC-DC converters.
Thermal performance is robust with a maximum junction temperature of 175°C and a surge current handling capability of up to 882 A, ensuring durability under demanding surge conditions. The device’s positive temperature coefficient enhances safe operation in parallel configurations.
Compliant with automotive-grade AEC-Q101 standards and being Pb-free and RoHS certified, the FFSP4065BDN-F085 diode meets rigorous quality and environmental requirements, suitable for automotive and industrial sectors.
Silicon Carbide Schottky Diode with superior switching and thermal performance. High current rating and voltage tolerance for demanding applications. Compact TO-220 3-pin package for easy through-hole installation. Excellent surge capability and temperature range supports harsh environments.
Automotive compliant and environmentally friendly design. This diode is extensively used in industrial power supplies, automotive electric systems, HVAC inverters, manufacturing machinery, and water treatment power modules.
Explore more high-quality semiconductors and electronic components within the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the FFSP4065BDN-F085 is 40 amperes.
This model can withstand a peak reverse repetitive voltage of 650 volts.
The maximum operating temperature for the FFSP4065BDN-F085 is 175°C.
It is housed in a compact TO-220 3-pin package suitable for through-hole mounting.
The maximum forward voltage drop is 2.4 volts, which helps reduce power losses.
It has a peak non-repetitive forward surge current capacity of up to 882 amperes.
The dimensions of the FFSP4065BDN-F085 are 10.67mm in length, 4.7mm in width, and 9.4mm in height.
Yes, it complies with the automotive-grade AEC-Q101 standards.
The minimum operating temperature is -55°C.
This diode is Pb-free and RoHS certified, meeting rigorous quality and environmental requirements.
It is suitable for high-power applications including hybrid electric vehicle (HEV) and electric vehicle (EV) onboard chargers and DC-DC converters.
The FFSP4065BDN-F085 is a Schottky rectifier with a configuration of 2x common cathode pair.
