STMicroelectronics Schottky Diode 100 V 30 A Surface Mount TO-263 3-Pin STPS30SM100SG-TR

STMicroelectronics presents the STPS30SM100SG-TR Schottky Diode, a reliable and efficient 3-pin surface mount semiconductor diode housed in a TO-263 package. This diode is designed to handle a maximum continuous forward current of 30 A and can block peak reverse voltages up to 100 V, making it suitable for power rectification and switching applications in electronics.

Its key feature is the low forward voltage drop of 0.63 V, which minimizes power loss and improves overall circuit efficiency. The diode supports a wide operating temperature range from -65°C to 150°C, ensuring stable performance under extreme environmental conditions. Additionally, it withstands high surge currents up to 530 A non-repetitively for transient conditions.

The compact TO-263 surface mount footprint measuring 10.4 mm in length, 9.35 mm in width, and 4.6 mm in height makes it ideal for automated PCB assembly and space-constrained designs. With three pins, the device facilitates easy integration in discrete semiconductor circuits.

Maximum continuous forward current of 30 A. Peak reverse repetitive voltage rating of 100 V. Low forward voltage drop of 0.63 V enhances power efficiency. Wide operating temperature from -65°C to 150°C. High surge current capability of 530 A non-repetitive.

Surface mount TO-263 package with dimensions 10.4 x 9.35 x 4.6 mm. Single diode configuration with 3-pin count. Manufactured in China to high-quality semiconductor standards.

This diode is suitable for electronic assemblies requiring efficient low-loss rectification, including industrial power conversion, telecommunications, and consumer devices. Browse more Semiconductor Diodes and components from STMicroelectronics and other leading brands in the Electronics & Electricals category at EnvMart.
