STMicroelectronics Schottky Diode 150 V 5 A Surface Mount TO-263 3-Pin STPS10150CG-TR

The STMicroelectronics STPS10150CG-TR Schottky diode is a power diode designed for efficient and reliable switching and rectification in electronic circuits and power supplies. This surface mount component is housed in a TO-263 (D2PAK) 3-pin package, making it suitable for automated PCB assembly and high-density applications.

Featuring a maximum continuous forward current of 5 A and a peak repetitive reverse voltage of 150 V, this diode is engineered to operate efficiently under medium power conditions. Its low forward voltage drop of 920 mV minimises power dissipation and enhances energy efficiency in circuit designs.

Designed to endure a wide temperature range from -65°C up to 175°C, it performs reliably in automotive, industrial, and consumer electronics applications. The diode’s peak non-repetitive forward surge current rating of 120 A allows it to handle transient overloads without damage, ensuring robust performance in transient-heavy environments.

Its common cathode configuration and a low peak reverse current of 2 mA contribute to reduced leakage currents and enhanced circuit stability. The small form factor with precise dimensional control (length 10.4 mm, height 9.35 mm, width 4.6 mm) supports compact and efficient PCB layouts, critical in modern electronic assemblies.

This Schottky diode is commonly used in power rectification, voltage clamping, and protection circuits across diverse sectors including industrial equipment, automotive electronics, power supplies, and consumer devices.

This diode features a common cathode configuration suitable for power and signal rectification. The maximum forward voltage drop is 920 mV ensuring efficient power conduction. Operating temperature ranges from -65°C to 175°C for reliable performance in harsh environments.

Peak non-repetitive forward surge current capability up to 120 A accommodates transient load conditions. Compact dimensions with 10.4 mm length, 9.35 mm height, and 4.6 mm width support space-saving PCB layouts. Low peak reverse current of 2 mA enhances device stability and reduces leakage losses.

The device is RoHS compliant and manufactured in China following standard semiconductor quality controls. Explore the full range of Schottky diodes and semiconductor devices offered by STMicroelectronics at EnvMart for advanced electronic design solutions.
