Altera Complex Programmable Logic Device MAX V 192 Cells 114 I/O 17.7 ns 240 Logic Elements In System 5M240ZT144C5N

Altera 5M240ZT144C5N is a complex programmable logic device belonging to the MAX V series, designed with 192 macro cells, 114 user I/Os, and 240 logic elements. It provides high-speed performance with a maximum propagation delay time of 17.7 ns and a maximum operating frequency of 152 MHz. Its architecture supports in system programmability and re-programmability, allowing engineers to optimize designs during production and deployment.

This TQFP package device features a compact height of 1.4 mm and length of 22 mm, making it suitable for surface mount applications. It operates within supply voltages of 1.71 to 1.89 V and supports individual output enable control, enhancing circuit control flexibility.

The device is engineered for industrial temperature ranges from 0°C to 85°C and conforms to RoHS environmental standards, ensuring safety and regulatory compliance. The low-power, non-volatile CPLD architecture allows instant-on configuration in half a millisecond or less and maintains standby current as low as 25 microamperes, aiding energy-efficient applications. Additionally, it includes a built-in internal oscillator for reliable timing and synchronization.

This CPLD is ideal for industrial, consumer electronics, and communications applications requiring programmable logic with low power consumption, fast configuration, and robust performance. It enables designers to create flexible and efficient logic circuits for various electronic systems.

This device supports in system programmability, enhancing flexibility in circuit design. It features a surface mount TQFP package with 144 pins facilitating integration onto PCBs. The device operates between 1.71 V minimum and 1.89 V maximum supply voltages.

Operating temperatures range from 0°C to 85°C, suitable for various industrial environments. Includes individual output enable control and supports re-programmability for design adjustments. Maximum operating frequency is 152 MHz, allowing high-speed logic operations.

The device complies with RoHS standards ensuring environmental safety. It features low-power, non-volatile architecture with instant-on configuration in 0.5 ms or less. Standby current is as low as 25 μA with fast power-down and reset operations.

Internal oscillator is included for streamlined timing control.
