DiodesZetex Silicon Junction Switching Diode 3 A 2-Pin Surface Mount 400 V SMC RS3G-13-F
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 2.3mm |
| Length | 7.11mm |
| Model | RS3G-13-F |
| Width | 6.22mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SMC |
| Sub Type | Silicon Junction |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Diode Configuration | Single |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 1.3V |
| Peak Reverse Recovery Time trr | 150ns |
| Maximum Forward Current If | 3A |
| Maximum Peak Reverse Repetitive Voltage Vrrm | 400V |
Key Features
- This diode configuration is a single silicon junction type suitable for switching applications.
- Maximum forward current rating is 3 amperes to support moderate current loads.
- Peak reverse recovery time is 150 nanoseconds for efficient switching performance.
- Maximum forward voltage drop is 1.3 volts ensuring low conduction losses.
- Operating temperature ranges from -65°C to 150°C for robust thermal stability.
- It accommodates a peak non-repetitive surge current of 100 amperes for transient tolerance.
- Compact SMC surface mount package with dimensions approximately 7.11 mm in length and 6.22 mm in width.
- It features 2 pins for surface mounting on printed circuit boards.
Product Description
DiodesZetex RS3G-13-F is a Silicon Junction Switching Diode designed for electronic and industrial applications where reliable switching performance is essential. This surface mount diode supports a maximum forward current of 3 amperes and a peak reverse voltage of 400 volts, making it suitable for moderate power electronic circuits.
The device features a single diode configuration with a rapid 150 nanosecond peak reverse recovery time, enabling fast switching speeds necessary for power conversion and signal processing in laboratory, manufacturing, and automotive electronics.
Its maximum forward voltage of 1.3 volts ensures efficient conduction with minimal power loss, while thermal stability is maintained across a wide operating temperature range from -65°C to 150°C, ensuring dependable operation in harsh environments.
The package type is a Surface Mount Component (SMC) with a compact 2-pin configuration, measuring approximately 7.11 mm in length, 6.22 mm in width, and 2.3 mm in height. It is optimized for automated PCB assembly in industrial and electronic manufacturing.
This diode is ideal for use in power supplies, switching regulators, and various semiconductor applications requiring fast recovery times and moderate current handling capabilities.
This diode configuration is a single silicon junction type suitable for switching applications. Maximum forward current rating is 3 amperes to support moderate current loads. Peak reverse recovery time is 150 nanoseconds for efficient switching performance.
Maximum forward voltage drop is 1.3 volts ensuring low conduction losses. Operating temperature ranges from -65°C to 150°C for robust thermal stability. It accommodates a peak non-repetitive surge current of 100 amperes for transient tolerance.
Compact SMC surface mount package with dimensions approximately 7.11 mm in length and 6.22 mm in width. It features 2 pins for surface mounting on printed circuit boards. Automotive standard and approvals are not applicable for this component.
Explore further selections in discrete semiconductors and Switching Diodes at EnvMart for your industrial and laboratory electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum forward current rating of this diode is 3 amperes, suitable for moderate current loads.
The peak reverse recovery time for the RS3G-13-F is 150 nanoseconds, enabling efficient switching performance.
This model can handle a maximum peak reverse repetitive voltage of 400 volts.
The SMC package dimensions are approximately 7.11 mm in length, 6.22 mm in width, and 2.3 mm in height.
The operating temperature range for this diode is from -65°C to 150°C, providing robust thermal stability.
This diode features a 2-pin configuration for surface mounting on printed circuit boards.
The maximum forward voltage drop for the RS3G-13-F is 1.3 volts, ensuring low conduction losses.
It accommodates a peak non-repetitive surge current of 100 amperes for transient tolerance.
This model utilizes a single silicon junction diode configuration, suitable for switching applications.
This diode is suitable for use in power supplies, switching regulators, and various semiconductor applications requiring fast recovery times.
The country of origin for this diode is India.
It supports surface mounting, optimized for automated PCB assembly in industrial and electronic manufacturing.
