| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.1mm |
| Length | 2mm |
| Model | BAT54SWFILM |
| Width | 1.25mm |
| Mount Type | Surface |
| Series | BAT54 |
| Maximum Operating Temperature | 150°C |
| Package Type | SC-70 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 300mA |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Series |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 1A |
| Maximum Forward Voltage Vf | 900mV |
| Peak Reverse Recovery Time trr | 5ns |
STMicroelectronics BAT54SWFILM is a Schottky Diode designed for surface mount applications. It features a peak reverse voltage of 40 V and a maximum continuous forward current of 300 mA, ensuring reliable operation in low-voltage, high-speed switching circuits.
Packaged in the compact SC-70 3-pin package, with dimensions of 2 mm length, 1.25 mm width, and 1.1 mm height, this diode is suitable for tight layout designs requiring efficient space usage.
The diode offers a low forward voltage drop of 900 mV and a fast peak reverse recovery time of 5 ns, making it ideal for power management, voltage clamping, and signal rectification tasks in industrial electronic circuits and automotive electronics where fast switching is required.
High efficiency and low forward voltage drop reduce power loss. Wide operating temperature range from -40°C to 150°C supports harsh environments. Peak surge forward current of 1 A withstands inrush currents safely. Minimal leakage current of 1 µA helps conserve energy.
Compact surface mount SC-70 package optimizes PCB space. Designed for durable industrial, automotive, and consumer electronics applications. Schottky barrier diode technology ensures fast switching and high efficiency. Series BAT54 diode configuration meets standard rectifier requirements.
This diode is commonly used in power converters, voltage protection circuits, and high-frequency switching power supplies. It is suitable for industrial manufacturing, automotive electronics, telecommunications, and consumer electronic devices. The compact form factor allows integration into sophisticated PCB designs, supporting modern electronics manufacturing.
