STMicroelectronics Schottky Diode 30 V 100 mA 3-Pin SOT-23 BAR43FILM

Name: STMicroelectronics Schottky Diode 30 V 100 mA 3-Pin SOT-23 BAR43FILM
Brand: STMicroelectronics
SKU: 219124
Price: 0.05 USD
Availability: InStock



Category Schottky Diode Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	0.95mm
Length	2.9mm
Model	BAR43FILM
Width	1.3mm
Mount Type	Surface
Series	BAR43
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Maximum Continuous Forward Current If	100mA
Peak Reverse Repetitive Voltage Vrrm	30V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	500nA
Peak Non-Repetitive Forward Surge Current Ifsm	750mA
Maximum Forward Voltage Vf	1V
Peak Reverse Recovery Time trr	5ns

Key Features

This diode features a maximum continuous forward current of 100 mA.
It offers a peak reverse repetitive voltage of 30 V.
The diode has a maximum forward voltage drop of 1 V for efficient operation.
Operating temperature ranges from -65°C to 150°C, suitable for various environments.
The compact SOT-23 package measures 2.9 mm length, 1.3 mm width, and 0.95 mm height.
Peak reverse current is rated at a low 500 nA to minimize leakage.
Peak non-repetitive forward surge current can reach 750 mA.
Fast recovery time of 5 ns allows high-speed switching applications.

Product Description

STMicroelectronics BAR43FILM Schottky Diode is a high-performance, single diode designed for surface mount applications. It is housed in a compact 3-pin SOT-23 package with dimensions 2.9 mm length, 1.3 mm width, and 0.95 mm height, facilitating placement in dense circuit boards.

This diode supports a maximum continuous forward current of 100 mA and a peak reverse repetitive voltage of 30 V, making it suitable for low-voltage rectification and switching tasks. Its maximum forward voltage of 1 V ensures efficient conduction with minimal power loss.

The diode operates reliably across a wide temperature range from -65°C to 150°C, enabling use in varying industrial, automotive, and consumer electronics environments. Its peak reverse current of 500 nA ensures low leakage current, improving circuit stability.

Equipped with a peak non-repetitive forward surge current of 750 mA, this diode can handle brief current surges without damage, enhancing durability. A very fast peak reverse recovery time of 5 nanoseconds supports rapid switching operations in power converters and high-frequency circuits.

This diode is ideal for use in industrial semiconductor applications and power supply components. The SOT-23 packaging ensures versatile PCB mounting and efficient thermal performance. Key uses include power rectification, voltage clamping, and high-speed switching circuits.

It is suitable for integration in industrial, automotive, and consumer electronics manufacturing. Explore a wide range of semiconductor diodes at EnvMart to support your electronics design and manufacturing needs.
