Vishay 1-Element Uni-Directional TVS Diode, Surface Mount DO-214 Package, 400 W Peak Pulse Power SMAJ36A-E3/61
Specifications
| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Height | 2.09mm |
| Length | 4.5mm |
| Model | SMAJ36A-E3/61 |
| Width | 2.79mm |
| Mount Type | Surface |
| Series | TRANSZORB TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 58.1V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 40V |
| Maximum Reverse Stand-off Voltage Vwm | 36V |
| Peak Pulse Power Dissipation Pppm | 400W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 6.9A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Single element diode providing reliable uni-directional transient voltage suppression.
- Surface mount package DO-214 with compact dimensions for PCB integration.
- Peak pulse power dissipation of 400 W ensuring protection under surge events.
- Minimum breakdown voltage of 40 V with maximum reverse stand-off voltage of 36 V.
- Clamping voltage rated at 58.1 V to limit transient voltages effectively.
- Wide operating temperature range from -55°C to 150°C supporting harsh conditions.
- Test current of 1 mA and maximum peak pulse current of 6.9 A for robust performance.
- Low maximum reverse leakage current of 1 μA minimizing power loss.
Product Description
Vishay SMAJ36A-E3/61 is a high-performance 1-element uni-directional TVS diode designed for transient voltage suppression applications in electronic circuits. This diode features a surface mount DO-214 package, facilitating easy integration into compact PCB layouts. It provides a peak pulse power dissipation of 400 W, effectively protecting sensitive components from transient voltage spikes and surge events in industrial and automobile electronics.
The diode exhibits a minimum breakdown voltage (Vbr) of 40 V and a maximum reverse stand-off voltage (Vwm) of 36 V, ensuring stable operation under normal circuit conditions. Clamping voltage of 58.1 V limits the voltage spikes to safe levels, thereby safeguarding downstream components. Its test current is 1 mA with a maximum peak pulse current (Ippm) of 6.9 A, ensuring high surge current robustness.
Operating temperature range from -55°C to 150°C allows for use in harsh industrial environments and automotive applications. The diode is compliant with the automotive standard AEC-Q101, guaranteeing reliable performance and quality for automotive electronic systems.
The compact size with 4.5 mm length, 2.79 mm width, and 2.09 mm height, along with a low maximum reverse leakage current of 1 μA, makes it ideal for dense circuit designs requiring high efficiency and low power loss.
Typical use cases include protection in power supplies, industrial machinery, motor controllers, automotive electronics, and communication equipment where transient voltage suppression is critical.
Single element uni-directional TVS diode ensuring precise transient voltage protection. 400 W peak pulse power dissipation handling high surge events. DO-214 surface mount package suitable for automated PCB assembly. Operating temperature range covers extreme environmental conditions.
Automotive grade with AEC-Q101 certification for reliability. Compact dimensions and low leakage current optimize space and power efficiency. Protects sensitive semiconductor devices from voltage transients and electrostatic discharges.
Choose Vishay SMAJ36A-E3/61 for robust, reliable transient voltage protection in demanding industrial and automotive applications. Browse more TVS Diodes and discrete semiconductors on EnvMart for your electronic component requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a peak pulse power dissipation of 400 W, which allows it to effectively protect sensitive components from transient voltage spikes and surge events.
The clamping voltage is rated at 58.1 V, which helps limit transient voltages to safe levels.
The minimum breakdown voltage (Vbr) is 40 V, ensuring stable operation under normal circuit conditions.
The maximum reverse stand-off voltage (Vwm) for this diode is 36 V.
It operates within a temperature range from -55°C to 150°C, making it suitable for harsh environments.
This unit can handle a maximum peak pulse current of 6.9 A, ensuring robust performance during surge events.
The diode is packaged in a surface mount DO-214 package, which facilitates easy integration into compact PCB layouts.
The maximum reverse leakage current is 1 μA, which minimizes power loss in the circuit.
This model is a single element diode, designed for uni-directional transient voltage suppression.
Yes, it is compliant with the automotive standard AEC-Q101, ensuring reliable performance for automotive electronic systems.
The dimensions are 4.5 mm in length, 2.79 mm in width, and 2.09 mm in height, making it compact for dense circuit designs.
This diode is suitable for applications such as protection in power supplies, industrial machinery, motor controllers, and automotive electronics where transient voltage suppression is critical.
