Samtec ASP Series Straight Surface PCB Socket 400-Contact 10 Row 1.27 mm Pitch Solder ASP-134485-01

Free Delivery in India | Lowest Global Shipping Charges

Samtec ASP Series Straight Surface PCB Socket 400-Contact 10 Row 1.27 mm Pitch Solder ASP-134485-01

Name: Samtec ASP Series Straight Surface PCB Socket 400-Contact 10 Row 1.27 mm Pitch Solder ASP-134485-01
Brand: Samtec
SKU: 216164
Price: 42.39 USD
Availability: InStock



Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin	United States
Voltage	339V
Brand	Samtec
Orientation	Straight
Current	2.7A
Model	ASP-134485-01
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Copper
Series	ASP
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Board-to-Board
Minimum Operating Temperature	-55°C
Number of Rows	10
Pitch	1.27mm
Standards/Approvals	RoHS
Number of Contacts	400
Contact Gender	Female
Connector System	Board-to-Board
Stacking Height	6.5mm

Key Features

Provides reliable 400-contact connection in a compact 10-row configuration.
Constructed with high-quality liquid crystal polymer housing for durability.
Designed for surface mounting with a straight orientation for easy assembly.
Supports current rating up to 2.7 A and voltage up to 339 V.
Features copper female contacts ensuring excellent conductivity.
Meets RoHS standards for compliance and environmental safety.
Operates reliably in temperatures from -55°C to 125°C.
Stacking height of 6.5 mm is suitable for dense PCB layouts.

Product Description

Samtec ASP-134485-01 is a high-performance straight surface PCB socket designed for board-to-board connector applications, accommodating 400 contacts arranged in 10 rows with a 1.27 mm pitch.

The socket features a robust liquid crystal polymer housing, ensuring mechanical durability and reliability in harsh industrial environments. It supports a current carrying capacity of 2.7 A and can operate up to a voltage of 339 V, making it suitable for a wide range of electronic assemblies.

With a straight connector orientation and surface mount design, this connector facilitates easy and secure solder termination to printed circuit boards. The copper female contacts provide excellent electrical conductivity and mechanical retention.

Operating temperature ranges from -55°C to 125°C allows use in demanding environmental conditions without performance degradation. Its 6.5 mm stacking height is ideal for applications requiring compact vertical space utilization.

This product complies with RoHS standards, ensuring environmentally responsible manufacturing. Produced in the United States, the ASP series connectors are trusted in diverse industrial, manufacturing, electronics, and communication sectors.

Provides reliable 400-contact connection in a compact 10-row configuration. Constructed with high-quality liquid crystal polymer housing for durability. Designed for surface mounting with a straight orientation for easy assembly.

Supports current rating up to 2.7 A and voltage up to 339 V. Features copper female contacts ensuring excellent conductivity. Meets RoHS standards for compliance and environmental safety. Operates reliably in temperatures from -55°C to 125°C.

Stacking height of 6.5 mm, suitable for dense PCB layouts. Manufactured in the United States with quality assurance. Ideal for industrial and electronic component applications requiring durable board-to-board connectors.
