Samtec HTSW Series Straight Through Hole Pin Header 16 Contacts 2.54 mm Pitch 2 Row Unshrouded HTSW-108-07-S-D
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 400, 450, 500, 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | HTSW-108-07-S-D |
| Mount Type | Through Hole |
| Special Features | Suitable for most high-temperature board processing |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | HTSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Features a straight, unshrouded design for easy soldering.
- Constructed with phosphor bronze contacts plated in gold for excellent conductivity.
- Housing material is liquid crystal polymer to withstand high temperatures.
- Suitable for board-to-board and wire-to-board connections.
- Operates reliably from -55°C to 125°C temperature range.
- Offers industry-standard 0.025" square post contact system for durability.
- Supports high voltage ratings up to 550V for robust electrical performance.
- Designed for through-hole mounting to ensure mechanical stability.
Product Description
Samtec HTSW-108-07-S-D is a high-quality straight through hole pin header designed for PCB interconnect applications. Featuring 16 contacts arranged in 2 rows with a 2.54 mm pitch, this connector provides reliable electrical connections for industrial, electronics manufacturing, and assembly use cases.
The contacts utilize phosphor bronze material with gold plating to ensure optimal conductivity and corrosion resistance. The housing is made from liquid crystal polymer, providing excellent thermal stability and durability in high-temperature environments, making it suitable for demanding electronics applications.
Designed for through-hole mounting, this unshrouded header allows easy soldering and mechanical robustness. It supports board-to-board and wire-to-board connector systems, facilitating flexible integration. The contact system features a 0.025" (0.635 mm) square post profile offering reliable mating and electrical contact.
Operating temperature range spans from -55°C to a maximum of 125°C, enabling usage across various industrial and commercial environments. The connector supports voltage levels up to 550 V, ensuring safe and effective operation in power and signal circuits.
Features a straight, unshrouded pin header design for versatile PCB connection. Phosphor bronze contacts plated with gold provide outstanding electrical performance. Liquid crystal polymer housing ensures high-temperature resistance and mechanical strength.
Through-hole mounting type guarantees robust physical connection. Compatible with board-to-board and wire-to-board connector systems. Wide operating temperature range from -55°C to 125°C supports diverse applications. High voltage rating up to 550 V for industrial and electronic device use.
Contact system utilizes .025" square posts for durable connections.
This Samtec HTSW series connector is ideal for electronic, industrial, manufacturing, and assembly sectors requiring reliable PCB interconnects. Explore more premium PCB headers and connectors in the Electronics & Electricals category at EnvMart to find solutions tailored to your project needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports voltage levels up to 550V, ensuring safe and effective operation in power and signal circuits.
It operates reliably within a temperature range of -55°C to 125°C, making it suitable for various industrial and commercial environments.
The contacts are made from phosphor bronze with gold plating for optimal conductivity, while the housing is constructed from liquid crystal polymer for high-temperature resistance.
This model features 16 contacts arranged in 2 rows with a 2.54 mm pitch, facilitating reliable electrical connections.
It is designed for through-hole mounting, which ensures mechanical stability and allows for easy soldering.
The contact system utilizes a .025" (0.635 mm) square post profile, providing reliable mating and electrical contact.
Yes, it is suitable for most high-temperature board processing due to its liquid crystal polymer housing material.
It supports both board-to-board and wire-to-board connector systems, allowing for flexible integration in various applications.
This connector features a straight orientation, which aids in easy installation and soldering.
The contacts in this model are male, designed for reliable connections with compatible female connectors.
The pin header is manufactured in the United States, ensuring adherence to quality standards.
It is designed to withstand high temperatures during board processing, making it suitable for demanding electronics applications.
