Preci-Dip 6 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder, 3A 801-87-006-10-012101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 6 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder, 3A 801-87-006-10-012101

Name: Preci-Dip 6 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder, 3A 801-87-006-10-012101
Brand: Preci-Dip
SKU: 215448
Price: 1.12 USD
Availability: InStock



Category SIL Sockets Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	100, 150V ac
Brand	Preci-Dip
Orientation	Straight
Current	3A
Length	15.24mm
Depth	4.2mm
Width	2.54mm
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate
Contact Material	Brass, Beryllium Copper Alloy
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Tin, Gold
Number of Contacts	6

Key Features

The socket features 6 contacts made of brass and beryllium copper alloy ensuring durability.
Contact plating includes tin and flash gold for excellent conductivity and corrosion resistance.
The straight orientation with 2.54 mm pitch fits standard PCB layouts.
Housing is constructed from fibreglass reinforced polycyclohexylenedimethylene terephthalate for high thermal stability.
Operates reliably in temperatures ranging from -55°C to 125°C.
Designed to carry currents up to 3 A, suitable for moderate power applications.
Termination type is solder, compatible with standard PCB assembly techniques.
Swiss-made quality from Preci-Dip ensuring consistency and reliability in electronic applications.

Product Description

Preci-Dip 801-87-006-10-012101 6 Way SIL Socket is a high-quality through hole IC socket designed for electronic applications requiring reliable signal connections at voltages up to 100 V AC and 150 V DC. The socket's 2.54 mm pitch and straight orientation facilitate easy integration into standard PCB designs.

This socket is engineered with contacts composed of brass and beryllium copper alloy, enhanced with tin and flash gold plating to deliver optimal conductivity and resist corrosion over time. Its fibreglass reinforced polycyclohexylenedimethylene terephthalate housing provides mechanical strength and thermal resistance, supporting operation from -55°C up to 125°C.

Measuring 15.24 mm in length with a depth of 4.2 mm and a pitch and width of 2.54 mm, the compact design allows for efficient use of PCB real estate in industrial, manufacturing, and electronic instrumentation contexts. The solder termination type ensures robust mechanical and electrical connections during PCB assembly.

Its current rating of 3 A supports moderate electrical loads, making it suitable for a broad range of electronic device interfaces. The socket has 6 contacts ideal for signal or low power applications. Its contact material alloy and plating provide durability and electrical performance.

Operating temperature range supports use in harsh environments. Compact size enables versatile mounting configurations. Through hole mounting type offers secure PCB attachment. Solder termination offers compatibility with automated manufacturing processes.

Electrical ratings of 100 V AC and 150 V DC cover typical electronic control circuits. Manufactured in Switzerland ensuring premium quality and compliance.

This Preci-Dip model 801-87-006-10-012101 6 Way SIL Socket fits effectively in electronic component assemblies, enhancing connection reliability in sectors such as industrial control, laboratory equipment, and consumer electronics. Browse the Preci-Dip connector range at EnvMart for compatible components and accessories.

Explore more products in our SIL Sockets category.
