Preci-Dip 3 Way Preci-Dip Straight Through Hole 1.27 mm Pitch SIL Socket 100 V AC, 150 V DC, 1A 851-87-003-10-001101

Preci-Dip 851-87-003-10-001101 3 Way SIL Socket is a high-precision electronic component providing a reliable straight through hole connection with a 1.27 mm pitch. Rated for 1A current and 100 V AC / 150 V DC voltages, it is designed for demanding industrial and electronic uses including PCB mounting.

The socket contacts are fabricated from a combination of beryllium copper alloy and brass, enhancing mechanical strength and electrical performance. These are plated with tin and gold to ensure corrosion resistance and excellent conductivity. The robust housing uses fibreglass reinforced polycyclohexylenedimethylene terephthalate for thermal and mechanical durability, enabling operation in temperatures from -55°C to 125°C.

The product features a solder termination type, straight orientation, and through hole mounting for effective installation and stable connections. The compact size (4.22 mm length, 4.1 mm depth, 2.2 mm width) makes it ideal for integration into dense PCB layouts.

Manufactured in Switzerland, this SIL socket adheres to high standards although no specific approvals are listed. It is suited for industrial electronics, manufacturing, instrumentation, and power supply applications where assured contact reliability is essential.

The socket features a 1.27 mm pitch suitable for precise circuit connections. It supports a current rating of 1A and voltage ratings of 100 V AC and 150 V DC. Contact materials consist of beryllium copper alloy and brass with tin and gold plating for optimal conductivity.

Housing is made from fibreglass reinforced polycyclohexylenedimethylene terephthalate for durability. Designed for solder termination type with straight orientation and through hole mount. Operates reliably in temperatures ranging from -55°C to 125°C.

Compact dimensions measuring 4.22 mm length, 4.1 mm depth, and 2.2 mm width enable easy PCB integration. Manufactured in Switzerland to high-quality Swiss standards.

Preci-Dip products like this SIL socket are widely used in electrical and electronics manufacturing for their precision and reliability. Browse the Electronics Components category at EnvMart for compatible connectors and accessories.
