Preci-Dip 9 Way Preci-Dip Straight Through Hole SIL Socket 2.54 mm Pitch 150V dc, 3A 801-87-009-10-001101

Preci-Dip 801-87-009-10-001101 is a 9 Way SIL (Single Inline) Socket designed for electronic components requiring a 2.54 mm pitch and through hole mounting. Operating at 150V dc and supporting 3A current, this socket ensures safe and reliable electrical connections in circuit boards.

The contacts are made from a combination of beryllium copper alloy and brass and feature tin plating with a flash of gold, enhancing conductivity and corrosion resistance. The durable housing is molded from fiberglass reinforced polycyclohexylenedimethylene terephthalate, providing excellent mechanical stability and thermal resistance.

This socket's operating temperature range is from -55°C to 125°C, making it suitable for a wide range of industrial and electronic applications. It terminates by soldering, making it ideal for printed circuit board installations that require robust and stable mechanical and electrical connections.

Dimensions are precisely controlled with a length of 22.86 mm, width and pitch set at 2.54 mm, and a depth of 7 mm, providing compatibility with standard electronic assemblies. The product is manufactured in Switzerland, ensuring premium quality and consistency.

This Preci-Dip socket is widely used in industrial electronics, laboratory testing equipment, prototyping, and commercial electronics manufacturing settings due to its reliable performance and high endurance.

The socket has 9 contact points suitable for electronic component connections. Constructed with beryllium copper alloy and brass contacts for reliable conductivity. Contacts are plated with tin and gold for corrosion resistance and enhanced signal integrity.

Housing material is fiberglass reinforced polycyclohexylenedimethylene terephthalate ensuring durability. The socket operates within a temperature range of -55°C to 125°C, supporting solder termination. Compact dimensions with a length of 22.86 mm, width and pitch of 2.54 mm, and depth of 7 mm.

Designed as through-hole mount type for PCB integration. Manufactured in Switzerland with high-quality standards. Ideal for precision electronics assembly and prototypes in industrial, laboratory, and manufacturing environments.
