Preci-Dip 4 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder 399-87-104-10-003101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 4 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder 399-87-104-10-003101

Name: Preci-Dip 4 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder 399-87-104-10-003101
Brand: Preci-Dip
SKU: 215194
Price: 0.79 USD
Availability: InStock



Category SIL Sockets Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	100, 150V ac
Brand	Preci-Dip
Orientation	Right Angle
Current	3A
Length	10.16mm
Depth	2.54mm
Width	2.95mm
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate
Contact Material	Beryllium Copper Alloy, Brass
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Tin, Gold
Number of Contacts	4

Key Features

This SIL socket accommodates 4 contacts for reliable electrical connection.
Contacts are made from beryllium copper alloy and brass, plated with tin and gold for durability.
The socket features a right angle orientation with a through-hole mount type for PCB integration.
Termination is through soldering, supporting current up to 3 amps.
Housing is constructed from fibreglass reinforced polycyclohexylenedimethylene terephthalate for thermal stability.
Operating temperature ranges from -55°C minimum to a maximum of 125°C.
The pitch between contacts is precisely 2.54 mm to match industry standards.

Product Description

Preci-Dip 399-87-104-10-003101 4 Way Right Angle Through Hole SIL Socket with 2.54 mm pitch supports electrical loads of 100 V AC and 150 V DC. It is designed for secure and reliable solder termination on printed circuit boards.

This SIL socket includes 4 contacts composed of beryllium copper alloy and brass, which are plated with tin and gold to ensure optimal conductivity and resistance to wear. The right angle configuration facilitates space-saving PCB layouts, while the through-hole mount type ensures robust mechanical stability.

The housing is made from durable fibreglass reinforced polycyclohexylenedimethylene terephthalate, capable of operating between the temperature range of -55°C to 125°C, making it suitable for demanding industrial, electronic, and telecommunication applications.

The product measures 10.16 mm in length, 2.95 mm in width, and 2.54 mm in depth with a standardized 2.54 mm pitch matching standard IC pin spacing. The solder termination type is preferable for permanent mounting and reliable electrical contact, supporting up to 3 amperes of current.

This SIL socket ensures secure, low-resistance electrical connections for sensitive electronic components. Right angle and through-hole design aids in efficient PCB assembly and space optimization. Robust materials and gold plating enhance durability under challenging conditions.

Suitable for industrial, electronics manufacturing, and communications hardware applications. Complies with UL 94V-0 flame retardant standards for safety.

Preci-Dip products are known for precision and quality, making this model ideal for electronics engineers and assembly professionals seeking reliable IC socket solutions. Explore the Electronics Components and SIL Sockets category for additional connectivity products.
