Preci-Dip 7 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 100 V ac, 150V dc, Solder, 3A 801-87-007-10-001101

Preci-Dip 801-87-007-10-001101 7 Way SIL Socket is engineered for electronic and electrical applications requiring robust and reliable connections with a 2.54 mm pitch and a current capacity of 3A. The socket features a straight through-hole mount style, ensuring ease of integration on printed circuit boards.

The contacts are manufactured from a Brass and Beryllium Copper Alloy with gold and tin plating to enhance conductivity and resistance to corrosion. The housing material is Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate, providing high mechanical strength and electrical insulation.

This connector operates safely at voltages of 100 V ac and 150 V dc, with a temperature tolerance ranging from -55°C to 125°C, making it suitable for use in diverse industrial, commercial, and laboratory environments.

The socket’s compact size, with a length of 17.78 mm, depth of 7 mm, and a 2.54 mm pitch, supports efficient space utilization on circuit boards. It is terminated by soldering for secure electrical and mechanical connection.

Applications for this SIL socket include industrial electronic assemblies, power supply interfaces, and general circuit interconnects. Its Swiss engineering ensures quality and compliance with UL 94V-0 standard for flame resistance.

This socket features 7 contacts suitable for secure electronic connections. Constructed with Brass and Beryllium Copper Alloy to ensure electrical conductivity and durability. Contacts are plated with Gold and Tin for enhanced corrosion resistance and reliable performance.

Housing is made from Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate for robust insulation and mechanical stability. Supports solder termination and through-hole mounting for straightforward PCB installation.

Designed to operate continuously from minimum -55°C up to 125°C maximum temperature. Rated for 3A current with voltage handling of 100 V ac and 150 V dc. Compact physical dimensions optimize PCB space utilization. Explore more SIL Sockets at EnvMart for diverse connector solutions catering to electronics manufacturing, prototyping, and industrial automation.
