Preci-Dip 6 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 150V dc, Solder Termination 801-87-006-20-002101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V dc |
| Brand | Preci-Dip |
| Orientation | Right Angle |
| Current | 3A |
| Length | 15.24mm |
| Depth | 2.54mm |
| Width | 2.95mm |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate |
| Contact Material | Beryllium Copper Alloy, Brass |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.54mm |
| Contact Plating | Tin, Gold |
| Number of Contacts | 6 |
Key Features
- Constructed with beryllium copper alloy and brass contact materials for durability.
- Supports a current rating of 3A with tin and gold plated contacts.
- Designed for right angle orientation with through-hole mount type.
- Housing made from fibreglass reinforced polycyclohexylenedimethylene terephthalate for strength.
- Operates at voltages up to 150V dc with solder termination.
- Functions reliably in temperature ranges from -55°C to 125°C.
- Compact dimensions of 15.24mm length, 2.95mm width, and 2.54mm depth.
- Swiss origin ensures quality manufacturing standards.
Product Description
Preci-Dip model 801-87-006-20-002101 is a 6 Way SIL Socket featuring a right angle through-hole design with a 2.54 mm pitch, rated for 150V dc and supporting 3A current. This component is engineered for high reliability in electronic assemblies, providing excellent electrical performance through beryllium copper alloy and brass contact materials. The contacts are plated with tin and gold to ensure durability and corrosion resistance.
The socket's housing material consists of fibreglass reinforced polycyclohexylenedimethylene terephthalate, offering mechanical strength and stability. It is suitable for solder termination in through-hole mounting applications. Operating temperature ranges from -55°C minimum to 125°C maximum, enabling use in various industrial, laboratory, and commercial electronic environments.
With precise dimensions of 15.24 mm length, 2.95 mm width, and 2.54 mm depth, this SIL socket is designed to optimize PCB space while maintaining robust connectivity. This model is manufactured in Switzerland, adhering to high-quality standards without specific certifications.
Constructed from beryllium copper alloy and brass contact materials for excellent conductivity and durability. Solder termination type designed for easy and reliable PCB mounting. Right angle orientation facilitates space-saving designs in electronic circuits.
Contact plating with tin and gold enhances corrosion resistance and longevity. Compatible with up to 150V dc voltage and 3A current for varied applications. Fibreglass reinforced housing provides high mechanical strength.
Can withstand operating temperatures between -55°C and 125°C. Compact footprint with precise pitch and dimension specifications.
This Preci-Dip SIL socket is an ideal choice for electronics manufacturing sectors, including industrial equipment, instrumentation, and telecommunications. Its reliable performance supports demanding applications requiring stable power and signal connections. Explore the range of Preci-Dip sockets and components available at EnvMart to enhance your electronic system designs.
Explore more products in our SIL Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at a maximum voltage of 150V dc.
This socket supports a current rating of 3A.
The socket has a length of 15.24mm, a width of 2.95mm, and a depth of 2.54mm.
The contacts are made from beryllium copper alloy and brass, ensuring good conductivity and durability.
It features a solder termination type designed for easy and reliable PCB mounting.
This model is designed for a right angle orientation, facilitating space-saving designs in electronic circuits.
It can operate within a temperature range of -55°C to 125°C.
The housing is made from fibreglass reinforced polycyclohexylenedimethylene terephthalate, providing mechanical strength.
This model features 6 contacts.
The pitch of this socket is 2.54 mm.
It is manufactured in Switzerland, adhering to high-quality standards.
It is suitable for use in industrial equipment, instrumentation, and telecommunications among other electronic applications.
