Preci-Dip 110 2.54 mm Pitch Vertical 32 Way Through Hole Turned Pin Open Frame DIL Socket 1A 110-87-432-41-001101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 110 2.54 mm Pitch Vertical 32 Way Through Hole Turned Pin Open Frame DIL Socket 1A 110-87-432-41-001101

Name: Preci-Dip 110 2.54 mm Pitch Vertical 32 Way Through Hole Turned Pin Open Frame DIL Socket 1A 110-87-432-41-001101
Brand: Preci-Dip
SKU: 215428
Price: 4.01 USD
Availability: InStock



Category DIL Socket Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	100, 150V ac
Brand	Preci-Dip
Orientation	Vertical
Current	1A
Frame Type	Open Frame
Length	40.6mm
Depth	2.8mm
Width	12.6mm
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Beryllium Copper Alloy, Brass
Series	110
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Tin, Gold
Number of Contacts	32
Pin Type	Turned
Row Width	10.16mm
Stock numbers	702-0691 , 702-2704 , 702-2701 , 702-2713 , 702-2767, 702-2779 , 702-2773 , 702-2798 and 702-2808 are without a centre bar

Key Features

32 contact points with a 2.54 mm pitch for reliable connectivity.
Vertical open frame design enables efficient soldering and testing.
Turned pin type with through hole mounting for PCB installation.
Constructed from beryllium copper alloy and brass for durability.
Contact plating of tin and gold ensures corrosion resistance.
Fibreglass reinforced polyethylene terephthalate housing provides insulation and mechanical strength.
Operates safely between -55°C and 125°C.
Rated for voltages of 100 to 150V AC and current of 1A.

Product Description

Preci-Dip model 110-87-432-41-001101 is a vertical 32 way DIL socket featuring a 2.54 mm pitch with an open frame design. It supports through hole mounting and turned pin types suitable for PCB installations requiring robust, high-reliability connections rated to 1 amp current.

Constructed from high-quality beryllium copper alloy and brass contacts plated with tin and gold, this socket offers excellent electrical conductivity and corrosion resistance. The housing is made from fibreglass reinforced polyethylene terephthalate providing strong insulation and mechanical protection.

This socket operates over a wide temperature range from -55°C up to 125°C and supports 100 to 150 volts AC, making it suitable for a variety of electronic applications requiring durable and reliable IC connections.

The dimensions include a length of 40.6 mm, width of 12.6 mm, depth of 2.8 mm, and a row width of 10.16 mm, ensuring precise fitting on printed circuit boards. It complies with the UL 94V_0 flame retardant standard and is manufactured in Switzerland, assuring high manufacturing quality.

32 contact points with 2.54 mm pitch for secure connections. Open frame vertical design facilitates easy soldering and testing. Turned pin with through hole mount ensures strong PCB attachments. Durable materials: beryllium copper alloy, brass with tin and gold plating.

High-performance insulating housing made from fiberglass reinforced PET. Temperature operating range from -55°C to 125°C. Rated for 1 amp current and 100-150V AC voltage. Compact dimensions suitable for various electronic assemblies.

Manufactured in Switzerland with UL 94V_0 compliance.

This product is widely used in electronics manufacturing, laboratory instrumentation, industrial control systems, and other applications that require dependable IC socket connectors. The open frame design improves thermal management and allows visual inspection during assembly.

For further related components, explore the DIL Socket category at EnvMart to find compatible sockets and adapters from established brands.
