Preci-Dip Spring Loaded Connector 12 Contacts 2.54 mm Pitch 2 Row Shrouded Through Hole Mount 150V 3.5A 813-S1-012-10-017101

Preci-Dip 813-S1-012-10-017101 is a high-quality Spring Loaded Connector designed for printed circuit board applications requiring reliable electrical contacts and robust mechanical performance.

The connector features 12 gold-plated brass contacts arranged in 2 rows with a pitch of 2.54 mm, making it compatible with standard DIL PCB layouts. Its fiberglass reinforced polyethylene terephthalate housing provides mechanical strength and excellent insulation properties.

With a current rating of 3.5 amps and a voltage rating of 150 volts, this connector supports demanding electronic assemblies. Operating temperature ranges from -55°C to 125°C, ensuring stable performance under extreme environmental conditions.

The spring-loaded contacts maintain consistent electrical connectivity despite vibration or mechanical movement, reducing issues like micro-discontinuities and improving reliability. Contact termination is through-hole solder type, and the contact gender is male. The connector is shrouded for added protection and safety.

Manufactured in Switzerland, the connector meets the UL 94V-0 flammability standard and is suitable for industrial automation, electronics manufacturing, laboratory instrumentation, and control gear applications.

This connector features 2 rows of shrouded, straight through hole spring loaded contacts. It supports a current rating of 3.5A and voltage rating of 150V. Contacts are made of brass with gold plating ensuring low resistance and corrosion resistance.

Housing is made of fiberglass reinforced polyethylene terephthalate for durability and mechanical stability. Operating temperature ranges from -55°C to 125°C, making it suitable for harsh environments. The spring-loaded design guarantees stable electrical connection with low contact resistance even under vibration or movement.

Termination is by solder and contact gender is male. Pitch and row pitch are both 2.54 mm, compatible with standard DIL PCB layouts. Manufactured in Switzerland and meets UL 94V-0 flammability standard. This connector is ideal for industrial, electronics manufacturing, and laboratory PCB applications.
