Preci-Dip 2.54 mm Pitch Vertical 16 Way Surface Turned Pin Open Frame DIL Socket, 1A 110-87-316-41-105101

Preci-Dip 110-87-316-41-105101 is a 16 way vertical DIL (Dual In-line) socket featuring a 2.54 mm pitch and open frame design, engineered for surface mount applications. This component is designed to provide reliable and durable connections in electronic devices requiring compact and consistent pin spacing.

The socket utilizes a combination of beryllium copper alloy and brass for contact materials, plated with gold and tin to ensure high conductivity and resistance to corrosion. It supports an electrical current of 1 ampere and is rated for operation at voltages up to 150 volts AC, suitable for various low-power electronic circuits.

With a vertical orientation and a precise 7.62 mm row width, this open frame DIL socket allows for effective circuit board assembly and straightforward in-circuit testing. The surface mount type termination features solder connections optimized for reflow processes, including vapor phase soldering with gull wing terminations, enhancing mechanical strength and reliability.

The socket operates within a temperature range of -55°C to 125°C, making it suitable for use in demanding industrial, electronic manufacturing, and testing environments. Its housing is fabricated from fiberglass reinforced polyethylene terephthalate, providing mechanical stability and resistance to environmental stresses.

Key design details include compact physical dimensions of 20.3 mm length, 10.1 mm width, and 2.8 mm depth, making it appropriate for dense PCB layouts. This product is part of Preci-Dip's 110 series sockets and is manufactured in Switzerland, ensuring high-quality Swiss engineering standards.

The socket features a vertical orientation with an open frame design for reliable connections. It accommodates 16 contacts with 2.54 mm pitch and 7.62 mm row width. Constructed with beryllium copper alloy and brass with gold and tin plating.

Supports 1A current and voltages up to 150V AC. Surface mount design with solder termination for reflow soldering processes. Temperature range from -55°C to 125°C for industrial applications. Compact dimensions suited for PCB integration in electronic devices.

Housing made from fiberglass reinforced polyethylene terephthalate for strength. Manufactured in Switzerland under the Preci-Dip 110 series standards.

This DIL Socket is ideal for use in industrial electronics manufacturing, laboratory equipment, prototyping, and testing applications where secure, high-quality connections are critical. Explore more electronic components and sockets suited for diverse industrial and laboratory uses with EnvMart’s comprehensive catalog.
