Preci-Dip 813 Series Straight Through Hole Spring Loaded Connector, 10 Contacts, 2.54 mm Pitch, 2 Row 813-S1-010-10-017101

Preci-Dip 813-S1-010-10-017101 is a new spring loaded connector designed for robust and reliable PCB connections. It features 10 male contacts arranged in 2 rows with a 2.54 mm pitch, suitable for through hole mounting.

The connector housing is manufactured from fibreglass reinforced polyethylene terephthalate providing durability and electrical insulation. Brass contacts with gold plating guarantee stable electrical conductivity and superior corrosion resistance even in demanding environments.

Designed to operate safely within a voltage rating of 150 V and a current capacity of 3.5 A, this connector performs reliably across a wide temperature range from -55°C to 125°C. The straight orientation and solder termination offer easy assembly on printed circuit boards.

The spring-loaded contact mechanism minimizes resistance and ensures continuous, low-resistance electrical connection, even when subjected to vibration or movement. The shrouded housing design provides additional protection to contacts and enhances safety during handling.

Key mechanical dimensions include a 4 mm height plastic body and a plunger stroke length of 1.4 mm, supporting compact and efficient PCB layout designs. This component is particularly suited for industrial, electronic manufacturing, and laboratory applications requiring secure and stable multipoint electrical connections.

Rated current of 3.5 A ensures reliable electrical performance. Housing made of fibreglass reinforced polyethylene terephthalate for durability. Brass contacts plated with gold provide excellent conductivity and corrosion resistance.

Operating temperature range from -55°C to 125°C suits varied environments. The connector supports a voltage of up to 150 V for versatile applications. Straight orientation and solder termination enable easy PCB integration.

Spring-loaded contacts reduce electrical resistance and maintain contact reliability under vibration. Shrouded design enhances protection and prevents accidental contact. Dimensions include 4 mm plastic body height and 1.4 mm plunger stroke length.
