Preci-Dip 813 Series Straight Through Hole Spring Loaded Connector, 12 Contacts, 2.54 mm Pitch, 2 Row 813-S1-012-10-014101

Preci-Dip 813-S1-012-10-014101 series Spring Loaded Connector is engineered for high-reliability electrical connections in demanding industrial and electronic assembly environments. This straight through hole, spring loaded connector features 12 gold-plated brass contacts arranged in a 2-row configuration with a 2.54 mm pitch, optimized for PCB integration.

The housing is crafted from fibreglass reinforced polyethylene terephthalate material, offering excellent mechanical strength and thermal resistance. The shrouded design ensures contact protection and alignment, enhancing connector longevity and reliability.

This connector supports a current rating of 3.5 amps at a maximum voltage of 150 volts and functions across a broad temperature range from -55°C to 125°C, making it suitable for industrial, manufacturing, test instrumentation, and electronic equipment applications.

The spring-loaded contacts provide low and stable electrical resistance even under mechanical vibration or movement, guaranteeing consistent electrical performance without micro-discontinuities. Ideal for use in laboratory instruments, automation systems, and heavy electronic assemblies where durable and reliable connections are critical.

Features a 2.54 mm pitch with two rows of gold-plated 12 brass spring-loaded contacts. Fibreglass reinforced polyethylene terephthalate housing ensures structural integrity and insulation. Through hole mount type with shrouded, straight orientation improves mechanical stability.

Operating temperatures from -55°C up to 125°C support harsh environment usage. Designed for 3.5 A current at 150 V maximum voltage applications. Male contacts with solder termination deliver secure electrical connections.

Manufactured in Switzerland, ensuring premium build quality and compliance.

Preci-Dip spring loaded connectors are a superior alternative to traditional connection methods, with multipoint contact technology providing consistent performance for dynamic or vibrating equipment. They are extensively used in electronic components, PCB headers, and power connectors sectors.
